Note: The 2-wire horn/strobe sync mode will only synchronize horns, horn/strobes, strobes with
synchronization capability.
7. For connection of smoke detectors, digital dialer (see Hookup Diagram, pg. 7).
Class A, Style Z Class B, Style W, X, Y, SW1 & SW2 Settings:
• For all Class B, Style W, X, Y, hookups SW1 & SW2 on the AL800LGK9E logic board must be open.
For all Class A, Style Z hookups SW1 & SW2 on the AL800LGK9E logic board must be closed.
Output Programming Selection Table:
Outputs must be programmed independently (OUT1 - OUT4)
Function
Input to Output Follower
Mode
Temporal Code 3 Mode
Steady Mode
For the above modes Dip Switch 4 determines which Input controls
the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by input 1.
Switch 4 in the OFF position causes output(s) to be controlled by input 2.
Note: It is required to control visual notification appliances (strobes) via input 1 (IN1)
and audible notification appliances (horns) via input 2 (IN2). This allows audible
notification appliances (horns) to be silenced while visual notification appliances (strobes) continue to operate. The
FACP must be capable of a visual annunciation to the silencing status of the output or zone(s) to which the
AL602ULADA (NAC Power Extender) is connected.
Switch Positions
Function
Amseco Sync
Mode*
Faraday
Sync Mode*
Gentex
®
Sync Mode*
Gentex is a registered trademark
of Gentex Corporation.
System Sensor
®
Sync Mode*
1, 2, 4
System Sensor is a registered
trademark of Honeywell.
CooperWheelock
®
Sync Mode*
2, 3, 4
CooperWheelock is a
registered trademark of
Cooper Wheelock.
- 4 -
Switch Positions Descriptions
ON OFF
1 2, 3
3 1, 2
1, 2, 3
Sync Mode Selection Table:
Descriptions
ON OFF
This mode is designed to work with the Amseco series of horns, strobes, and
1, 3,
horn/strobes to provide a means of synchronizing the Temporal-coded horns,
2
synchronizing the flash timing of the strobe, and silencing the horns of the horn/
4
strobe combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the Faraday series of horns, strobes, and horn/
strobes to provide a means of synchronizing the Temporal-coded horns, synchro-
2, 4 1, 3
nizing the flash timing of the strobe, and silencing the horns of the horn/strobe
combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the Gentex
1, 2,
strobes to provide a means of synchronizing the Temporal-coded horns, synchro-
nizing the flash timing of the strobe, and silencing the horns of the horn/strobe
3, 4
combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the System Sensor
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
3
synchronizing the one-second flash timing of the strobe, and silencing the horns of
the horn/strobe combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the CooperWheelock series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
1
synchronizing the one-second flash timing of the strobe, and silencing the horns of
the horn/strobe combination over a two-wire circuit while leaving strobes active.
Output follows signal it receives from the corresponding input (i.e.
FACP Sync module - maintains synchronization of
notification appliance circuit).
Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.
A steady output signal will be generated.
This mode will accept steady or pulsing input.
(AL800LGK9E Board)
Output Dip Switches
INPUT SELECT
STROBE SYNC
IN>OUT SYNC
series of horns, strobes, and horn/
®
series of horns, strobes,
®
TEMPORAL
