Specifications - Icom IC-­M71 Instruction Manual

13

SPECIFICATIONS

D GENERAL
• Frequency coverage
• Mode
• Power supply requrement
• Current dran
(at 7.2 V DC; approx.)
TX Hgh
(at 6 W)
TX Md.
(at 3 W)
TX Low
(at 1 W)
RX Max. audo
• Useable temperature range : –15°C to +55°C
• Frequency error
• Antenna connector
• Dmensons
(Projectons not ncluded)
• Weght
(wth BP-245N)
D TRANSMITTER
• Output power
(at 7.5 V DC)
• Modulaton system
• Max. frequency devaton
• Adjacent channel power
• Spurous emssons
32
: TX 156.000–161.450 MHz
RX 156.000–163.425 MHz
: 16K0G3E
: Specfied Icom's battery pack only
:
1.7 A
1.3 A
0.7 A
400 mA
(nternal speaker)
200 mA
(external speaker)
: ±1.5 kHz
: SMA (50 Ω nomnal)
: 52.5(W) × 125(H) × 30(D) mm
: Approx. 280 g
: 6 W* , 3 W*
(Hgh) (Mddle)
and 1 W*
(Low)
*1 W max. for ATIS operaton
: Varable reactance frequency mod-
ulaton
: ±5 kHz
: 70 dB
: 0.25 µW
D RECEIVER
• Receve system : Double-converson superhetero-
• Senstvty : –2 dBµ emf typcal
(20 dB SINAD)
• Squelch senstvty : –6 dBµ emf typcal
• Intermodulaton rejecton rato : 68 dB
• Spurous response rejecton rato:
• Adjacent channel selectvty : 70 dB
• Audo output power :
Internal speaker
External speaker
All stated specifications are subject to change without notice
or obligation.
dyne
(at threshold)
70 dB
0.6 W typcal
at 10% dstorton wth an
Ω
8 load
0.2 W
at 10% dstorton wth an 8
load
Ω
