Rear Panel - PROCEED PRE User Manual

tape2/
cd2 tuner tape1 ssp
L L
R R
p r e
PR O C E E D R
by MADRIGAL AUDIO L AB ORATORIES
Caution!
12
i n p u t s
R L R
cd1 bal/aux

Rear Panel

Disconnect all associated equipment from the AC mains
BEFORE making any signal connections and applying power
to the PRE.
1 SINGLE-ENDED AUDIO INPUTS
Accepts right-channel and left-channel audio signals from source equip-
ment with single-ended (RCA) outputs. Traditional single-ended audio
inputs are provided for a total of three components, designated:
tuner, and tape1
Connect the right-channel and left-channel single-ended outputs of your
various source components to the corresponding inputs on the PRE.
2 TAPE2/SSP INPUT
This single-ended audio input may be used either as a conventional in-
put for a second tape deck or as a dedicated surround sound processor
loop. In the latter case, the front left and right outputs of your surround
sound processor would be routed to the
through the PRE at unity gain (that is, with no change in volume), re-
gardless of the volume control setting of the PRE.
The ssp function gives the outboard surround sound processor control
over the volume of all the loudspeakers (including those normally con-
trolled by the PRE) when it needs that control. Returning the system to
two-channel stereo operation is then as simple as selecting a different
input. (See "Using Surround Sound Processors" for more information.)
o u t p u t s
L
rec1 rec2/ssp
main out
L
R L
R
.
.5A (250V) slo-blo 5x20mm
main out
R L
remote remote
IR turn-on
please see bottom panel for voltage and other information
input and passed
tape2/ssp
~ ac mains
mains fuse:
cd2,
