Learning New Functions On The Main Keypad - PROCEED PRE User Manual

learning new functions on the
main keypad
Device Buttons
pre
audio cd dvd aux
sat tv vcr cbl
power
standby
adjust channel
input record
mute
prev next
volume
play
rev fwd
volume
stop pause
Play Button
1 Select the mode in which you wish to learn the new function
by pressing the corresponding Device button.
Place the PRE remote and the original remote control to be
2
learned from, on a flat surface. Line up the remote controls
head-to-head, about two to three inches apart.
Press and hold both the Device button selected in Step 1
3
and the
play
the PRE remote shows
learning mode.
Each of the following steps must be completed within 20 seconds. If
NOTE:
the remote does not receive any new commands within the allotted time, it
will return to its normal operating mode.
Press and release a button on the PRE remote you have
4
selected to learn the new function. The LCD will show
.
READY
5 Press and hold the button on the original remote control for
about 3 seconds from which you are learning the new function.
The LCD on the PRE remote will show – – – – indicating that it
is receiving the information from the original remote control.
Release the button on the original remote control. The LCD
6
on the PRE remote will show
7 Press and hold the same button on the original remote once
again, for about three seconds. The LCD on the PRE remote
will flash
GOOD
verifying that the new function has been learned.
Repeat Steps 4 through 7 for any other buttons you wish to learn new
functions.
Once you have completed the learning for all the desired but-
8
tons in a Device mode, store the learned functions by press-
ing the device and play buttons simultaneously, once again.
The LCD in the PRE remote will show
to
the Device Mode
nal operating mode.
Once you have stored the learned functions, test the buttons that have been
taught. If any of the buttons do not operate as they should, please repeat from
Step 1 for those buttons.
If the LCD shows
NOTE: FAIL
remote was unable to learn the new functions. Please repeat from Step 4. If
the remote continues to show
following suggestions:
2" to 3"
button for about three seconds, until the LCD on
. the PRE remote is now in the
LEARN
.
RETRY
, the and then return to
Device Mode
. The remote has now returned to the origi-
at any time during the learning process, the PRE
FAIL during the learning process, please try the
,
LEARN
and then return
SAVED
23
