Teaching PRE Functions
to its Remote Control
Teaching PRE Front
Panel Commands
Device Buttons
pre
audio cd dvd aux
sat tv vcr cbl
power
standby
adjust channel
input record
mute
prev next
volume
play
rev fwd
volume
pause
stop
Play Button
If you inadvertently overwrite one or more PRE commands in your PRE remote
control, never fear—you don't have to obtain another PRE remote in order to
re-teach your own its PRE-specific commands. The PRE itself can send all of the
necessary IR commands from its
the PRE remote any or all of its pre-programmed commands, as well as some
optional special commands which are available to solve specific installation-
related difficulties.
The PRE has two special modes of operation into which is may be placed in
order to facilitate the "teaching" of remote control commands to its own (or
any other) learning remote control. The first allows you to easily teach the
commands for which there are corresponding front panel buttons. The second
allows you to teach "special" commands to the remote control for which there
are no corresponding front panel buttons.
1 Press and hold the
til "0L" appears in the display . A momentary press of the
button will, of course, simply place the PRE in
ance
mode . When you press and hold the
the PRE will wait for a few seconds to make sure that your
press-and-hold action is quite deliberate, and then enter a teach-
ing mode which allows you to program a learning remote con-
trol with infrared (IR) commands. The PRE's
show a number and the letter "L" (for "Learn") when in this
mode.
The PRE will display a "0L" code when it has entered its teach-
ing mode and is ready to help the remote control learn the
commands that correspond to the PRE's front panel buttons. If
no further buttons are pressed within approximately ten sec-
onds, the PRE will "time out" and return to normal
operation.
Line up the IR window of the PRE remote control with
2
the center of the
approximately 2"-3".
Press and hold both the
3
ton for about three seconds, until the LCD on the PRE remote
shows LEARN . The PRE remote is now in the learning mode.
Each of the following steps must be completed within 10 seconds. If
NOTE:
the remote does not receive any new commands within the allotted time, it
will return to its normal operating mode.
Press and release the corresponding button on the PRE remote
4
you have selected to re-learn the function. The LCD will show
.
READY
Notice that a yellow LED in the main display lights up briefly
after you press a button. This LED indicates that the PRE is
transmitting the command which corresponds to the button you
just pushed. Y ou may repeat this process until all commands
have been learned by your remote control.
main display window, enabling you to re-teach
balance (BAL) button on the front panel un-
balance
of the PRE, at a distance of
main display
Device and the
pre/audio
bal-
balance
button instead,
main display will
but-
play
35
