PROCEED PRE User Manual page 21

power
8
standby
mute
volume
volume
polarity
cd1
5
cd2
6
tape1
7
tape2
8
bal/aux
9
tuner
0
mono
display
balance
path
PRE OPERATIONAL CONTROLS
This section of the learning remote contains the most often used controls
for the Proceed PRE.
• pressing this button will place the PRE into
standby:
mode. As with all buttons on the learning remote, this button
can be "programmed over" if you wish. For example, you
may decide to leave the PRE "on" all the time and use the
standby button to turn another component on and off instead.
• mute : pressing this button duplicates the function of the
button on the front panel, reducing the volume of the
system by a user-selectable amount.
• volume +/– : these buttons normally adjust the overall system
volume, although they are also used in conjunction with other
buttons and/or menu items to vary most of the available sys-
tem adjustments.
• inverts the polarity (sometimes inaccurately called
polarity:
"absolute phase") of the outputs of the PRE. A second press
of this button will restore the outputs to their original, non-
inverting polarity.
• : selects the cd1 input (on either the main path or the
cd1
record path, depending which is selected).
• cd2 : selects the cd2 input (on either the main path or the
record path, depending which is selected).
• : selects the tape1 input (on either the main path or the
tape1
record path, depending which is selected).
• : selects the tape2 input (on either the main path or the
tape2
record path, depending which is selected).
• : selects the bal/aux input (on either the main path or
bal/aux
the record path, depending which is selected).
• : selects the tuner input (on either the main path or the
tuner
record path, depending which is selected).
• mono: sums the left and right channels of the PRE to a mono-
phonic signal, which is then routed to both left and right out-
puts.
• display : pressing this button will turn off the front panel dis-
play of the PRE to facilitate listening to music (or watching
movies) in a darkened room without visual distractions. The
PRE's display will turn back on momentarily when adjusting
the unit's operation in order to acknowledge the changes.
The display may be returned to its normal, always-on mode
by pressing the
display
• path : pressing this button toggles the PRE between the
and signal paths. Having selected a path, subsequent
record
source selections affect only that path.
• balance : pressing this button temporarily allows the
keys to affect the balance of the left and right speakers rather
–
than the overall volume.
For more information on the teaching your remote new functions, see
Programming and Using the Remote Control.
button again.
standby
mute
main
main
volume +/
21
