Rear Panel

Turn the volume on your preamplifier all the way down
before attempting to connect anything to your Proceed
AMP 2 or AMP 3.
1 AC MAINS RECEPTACLE
Connect the AC power cord (included in the accessory pack) to the I.E.C.-
standard AC receptacle on the rear panel of the AMP , then to the AC mains
outlet.
The Proceed AMP has been safety-tested and is designed
for operation with a three-conductor power cord. Do not
defeat the "third pin" or earth ground of the AC power cord.
