Learning Remote Control; Installing Batteries In The Remote Control - PROCEED PRE User Manual

installing batteries in
the remote control
pre
audio cd dvd aux
sat tv vcr cbl
power
standby
adjust channel
input record
mute
prev next
volume
play
rev fwd
volume
stop pause
vcr1 vcr2 laserdisc polarity
1 2 3
tv/vcr1 cd1 cd2 mode
4 5 6
tape1 tape2 bal/aux status
7 8 9
tuner mono
menu 0 enter
on
screen display input delay recall
master balance center rear sub
m1 m2 m3 m4
path
light

Learning Remote Control

This remote control uses four AAA 1.5V batteries. Please be sure to match
the batteries with the (+) and (–) markings inside the battery compartment
during installation.
A: To Open and Close the Battery Compartment Cover
To open the battery cover, push the latch forward toward the top of the
remote control, and lift the latch up.
To close the battery cover, slide the battery cover straight back in (toward
the top of the remote) and push down until it "clicks" into place.
B: Low Battery Message
When the Liquid Crystal Display (LCD) flashes L_BAT, the batteries
should be replaced.
Note: Batteries should last about 6 months under normal conditions.
This remote control will retain its programmed memory for up to one
year after the batteries are removed and up to ten years after the batteries
go "dead".
IMPORTANT NOTE:
The PRE's remote may be programmed to control up to eight devices, in-
cluding the PRE. Before using the remote, it is important to remember to
press the Device Control Selector button that corresponds to the unit you
wish to operate. Before using the remote with other products, follow the
instructions in Programming and Using the Remote Control.
It is also important to remember that many of the buttons on the remote
take on different functions, depending on the product selected using the
Device Control Selectors. Buttons not directly described on the follow-
ing two pages do not function with the PRE, but are available for use
with other devices.
19
