SPECIFICATIONS

D General
• Frequency coverage
• Channel spacing
• Mode
• No. of memory channels
• Acceptable power supply : 13.75 V* or 27.5 V* DC
(negative ground)
• Usable temp. range
• Frequency err
• Current drain
(at 13.75 V DC)
Tx
Rx
• Antenna impedance
• Dimensions
(projections not incl.)
• Weight (approx.)
15
: 118.000 to 136.975 MHz
: 25/8.33 kHz
: AM (6K00A3E)
: 99
(*Automatic selection)
: –20˚C to +55˚C
: ±1 ppm (0 to +40˚C)
:
5 A (at max. power)
4 A ( at max. AF)
0.5 A (at stand by)
: Standard 50 Ω with SWR<3:1
: 150 (W) × 50 (H) × 180 (D) mm
: 1.5 kg
D Transmitter
• Output power
• Modulation depth
• Modulation compression
• Amplitude mod. distortion : Less than 10%
• Audio frequency response : +2 dB to –4 dB from
• Adjacent channel power
• Conducted spurious emissions:
: 9 W ±1.5 dB (+15 to +35˚C)
9 W +2 dB, –3 dB
(–20 to +55˚C)
: More than 85%
: Linear: 85%, Max. : 95%
350 to 2500 Hz
More than –25 dB at 5000 Hz
(at 25 kHz channel spacing)
More than –25 dB at 3200 Hz
(at 8.33 kHz channel spacing)
: Less than 60 dB
(at 25 kHz channel spacing)
Less than 50 dB
(at 8.33 kHz channel spacing)
Less than –46dBm
(9 kHz to 30 MHz)
Less than –36 dBm for
harmonics
Less than –46 dBm for non-
harmonics
(30 MHz to 1 GHz)
Less than –30 dBm for
harmonics
Less than –40 dBm for non-
harmonics
(1 GHz to 4 GHz)
