• System Event Indicators - The status indicators on the UPS control panel and the event horn let
you know when the UPS system is operating in any mode other than Double conversion mode.
Only the Normal indicator is visible during normal UPS system operation. The other indicators
illuminate to indicate alarms or events. When an alarm occurs, first check these indicators to see
what type of event has taken place.
• System Event Messages - When a system event occurs, a message appears in the status bar of
the display. This message is also written to the Active Events log. Some notices and alarms may
be accompanied by an audible horn. To silence the horn, press any button once.

7.2 Steps to operate the UPS

The table below shows the menu structure of the 93PM UPS.
Main menu
Home
Meters
Mimics
Logs
46
Submenu
-
Meters summary
Input meters
Bypass meters
Output meters
Battery meters
UPS mimic
UPS module map
System overview
ESS
Active events
30–50kW
User's and Installation Guide
Functions
An overview of UPS operation,
including information on load,
efficiency and consumption.
A summary of the UPS or system
meters.
Detailed information on UPS or system
input meters.
Detailed information on UPS or system
bypass meters.
Detailed information on UPS or system
output meters.
Detailed information on UPS or system
battery meters.
An overview of UPS operation,
including information on load,
efficiency and consumption. If there is
an error, an error indicator is displayed
next to the affected part. Active events
log can be opened by tapping the error
indicator.
Module map shows the status of each
UPM.
System overview shows the status and
meters summary for each UPS.
ESS mimic screen shows the
approximated consumption and energy
savings of ESS mode.
All active events are displayed.
