Summary of Contents for Eaton 93PM

  • Page 1 Eaton 93PM UPS P-164000249 30–50kW User's and Installation Guide...
  • Page 3 Eaton 93PM UPS 30–50kW User's and Installation Guide...
  • Page 4 This is a product for commercial and industrial application in the second environment. Installation restrictions or additional measures may be needed to prevent disturbances. © 2012 Eaton Corporation All Rights Reserved The contents of this manual are the copyright of the publisher and may not be reproduced (even extracts) unless permission granted.

  • Page 5: Table Of Contents

    1.4 Environment....................................4 1.5 Symbols on the UPS and accessories............................5 1.6 Conventions used in this manual..............................6 1.7 For more information.................................. 6 2 Introduction to Eaton UPS..........................................8 2.1 Looking inside the UPS system..............................9 2.2 UPS operating modes................................10 2.2.1 Normal operating modes...............................10 2.2.1.1 Double conversion mode............................10...
  • Page 6 7.3 Signing in....................................47 7.4 Starting the UPS in double conversion mode.......................... 48 7.5 Starting the UPS in Bypass mode............................48 7.6 Starting the UPMs..................................49 7.7 Transfer from Double conversion mode to Bypass mode......................49 7.8 Transfer from Bypass to Double conversion mode........................50 7.9 Transfer from Double conversion mode to Energy Saver Mode....................50 7.10 Transfer from Energy Saver Mode to Double conversion mode....................50 7.11 UPS and critical load shutdown..............................
  • Page 7 List of Figures Figure 1-1: Recycling batteries symbol..............................5 Figure 1-2: WEEE symbol..................................6 Figure 2-1: Eaton 93PM UPS................................8 Figure 2-2: Main elements of the UPS system............................ 9 Figure 2-3: Path of current through the UPS in double conversion mode..................11 Figure 2-4: Path of current through the UPS in Energy Saver System....................12...
  • Page 8 List of Tables Table 3-1: Dimensions..................................18 Table 3-2: UPS cabinet weights................................18 Table 3-3: UPS cabinet clearances..............................18 Table 3-4: Air conditioning or ventilation requirements during full load operation................19 Table 3-5: Recommended multi-core cable and fuse sizes for 30-50kW UPS..................21 Table 3-6: Rated and maximum currents for rated power and voltage....................

  • Page 9: Safety Instructions

    1 Safety instructions IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. Please read all instructions before operating the equipment and save this manual for future reference. The UPS operates with mains, battery or bypass power.
  • Page 10 WARNING • The UPS is powered by its own energy source (batteries). The output terminals may be energised even when the UPS is disconnected from an AC source. To reduce the risk of fire or electric shock, install this UPS in a temperature and humidity controlled, indoor environment, free of conductive contaminants.

  • Page 11: Audience

    CAUTION • Installation or servicing should be performed by qualified service personnel knowledgeable of batteries and required precautions. Keep unauthorized personnel away from batteries. Consider all warnings, cautions, and notes before installing or replacing batteries. DO NOT DISCONNECT the batteries while the UPS is in Battery mode. •...

  • Page 12: Ce Marking

    • EMC Directive 89/336/EEC, 93/68/EEC and 92/31/EEC Declaration of conformity with UPS harmonised standards and directives EN 62040-1 (Safety) and EN 62040-2 (EMC) are available at www.eaton.eu/93PM or by contacting your nearest Eaton office or authorized partner. 1.3 User precautions The only user operations permitted are: •...

  • Page 13: Symbols On The Ups And Accessories

    UPS location must be ensured. A minimum air flow is 1.3 m³/ hour for the room where one 93PM UPS with internal VRLA batteries is placed. If more than one UPS with internal VRLA batteries are located in the same room, ventilation air flow must be dimensioned accordingly.

  • Page 14: Conventions Used In This Manual

    This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. Figure 1-2: WEEE symbol 1.6 Conventions used in this manual This manual uses these type conventions: •...
  • Page 15 • Regional locations and telephone numbers • A question about any of the information in this manual • A question this manual does not answer P-164000249 30–50kW Revision 1 User's and Installation Guide...

  • Page 16: Introduction To Eaton Ups

    2 Introduction to Eaton UPS The Eaton® 93PM uninterruptible power supply (UPS) is a true online, continuous-duty, transformerless, double-conversion, solid-state, three-phase system, supplying conditioned and uninterruptible AC power to critical load and protecting it from power failures. The UPS is used to prevent loss of valuable electronic information, minimize equipment downtime, and minimize the adverse effect on production equipment due to unexpected power problems.

  • Page 17: Looking Inside The Ups System

    2.1 Looking inside the UPS system The Eaton 93PM UPS is a continuous-duty, solid-state, transformerless, three-phase, true online system that provides conditioned and uninterruptible AC power to the UPS system’s output and critical load. The basic system consists of a rectifier, battery converter, inverter, static bypass switch, monitoring/operation control panel, integrated communication server, and digital signal processor (DSP) logic.

  • Page 18: Ups Operating Modes

    2.2 UPS operating modes UPS operating modes: • Normal operating modes: • In double conversion mode, the critical load is supplied by the inverter, which derives its power from rectified utility AC power. In this mode, the battery charger also provides charging current for the battery, if needed.

  • Page 19: Figure 2-3: Path Of Current Through The Ups In Double Conversion Mode

    Internal relay contacts Figure 2-3: Path of current through the UPS in double conversion mode During normal UPS operation, power for the system is derived from a utility input source. The front panel displays Normal, indicating the incoming power is within voltage and frequency acceptance windows.

  • Page 20: Energy Saver System Mode

    2.2.1.2 Energy Saver System mode In ESS mode the UPS safely provides mains current directly to the load when the input is within the acceptable limits by its voltage and frequency. Surge protection and some filtering is also provided, ensuring that clean power is delivered to the load equipment. Should there be any disturbances detected in the incoming power, the UPS switches to double conversion and continues to supply the critical load through its inverter.

  • Page 21: Stored Energy And Battery Mode

    2.2.2 Stored energy and battery mode When running normally in double conversion or ESS mode, the UPS automatically transfers to supply the load from batteries or other stored energy source if a utility power outage occurs, or if the utility power does not conform to specified parameters.

  • Page 22: Bypass Mode

    2.2.3 Bypass mode The UPS automatically switches to bypass mode if it detects an overload, load fault, or internal failure. The bypass source supplies the commercial AC power to the load directly. The UPS can also be commanded to transfer to bypass manually through the display. Figure 2-6 below shows the path of electrical power through the UPS system when operating in Bypass mode.

  • Page 23: Ups Features

    2.3 UPS features The Eaton UPS has many features that provide cost-effective and consistently reliable power protection. The feature descriptions provide a brief overview of the UPS standard features. 2.3.1 Advanced Battery Management Advanced Battery Management technology uses sophisticated sensing circuitry and a three-stage charging technique that extends the useful service life of UPS batteries while optimizing the battery recharge time.

  • Page 24: Battery System

    2.6 Battery system The Eaton 93PM 30-50kW UPS can be equipped with internal batteries to provide a 10-20 min runtime depending on UPS rating and load level. In addition, external battery cabinets can be introduced to the system to allow extended autonomy. Internal and external batteries can be used in parallel.

  • Page 25: Ups Installation Plan And Unpacking

    6. Have authorized service personnel perform preliminary operational checks and startup. NOTE Startup and operational checks must be performed by an authorized Eaton Customer Service Engineer, or the warranty terms specified in Warranty become void. This service is offered as part of the sales contract for the UPS.

  • Page 26: Table 3-1: Dimensions

    The UPS system installation must meet the following guidelines: • The system must be installed on a level floor suitable for computer or electronic equipment. The floor must be suitable for heavy weight and wheeling. • The system must be installed in a temperature and humidity controlled indoor area free of conductive contaminants.

  • Page 27: Figure 3-1: Ups Cabinet Dimensions

    • Recommended Operating Range: 20-25°C • Maximum Relative Humidity: 95%, noncondensing The UPS ventilation requirements are shown in the following table: Rating/kVA Input/output voltage Heat rejection BTU/h x 1000 30 kW 380/380 VAC, 400/400 VAC, 415/415 4.30 (1.3 kW) 40 kW 380/380 VAC, 400/400 VAC, 415/415 5.73 (1.7 kW) 50 kW...

  • Page 28: Ups System Power Wiring Preparation

    Figure 3-2: UPS cabinet clearances • X = min 200 mm • Y = min 800 mm • Z = 20 mm (recommended) 3.2.2 UPS system power wiring preparation NOTE If installing a maintenance bypass, a minimum of two separate feeds with upstream feeder breakers, or a single feed with two upstream feeder breakers, must be provided: one for the UPS or rectifier input breaker (if installed) and one for the maintenance bypass input.

  • Page 29: Table 3-5: Recommended Multi-Core Cable And Fuse Sizes For 30-50Kw Ups

    • Specification is for copper wire with a 90°C rating. • The bypass feed into this equipment uses three or four wires. The rectifier feed into this equipment uses three wires. The phases must be symmetrical about ground (from a Wye source) for proper equipment operation.

  • Page 30: Table 3-6: Rated And Maximum Currents For Rated Power And Voltage

    Rated Rated Rectifier input UPS Output/ Bypass Battery power voltage 415V Table 3-6: Rated and maximum currents for rated power and voltage See the table below for power cable terminations. Terminal function Terminal Function Tightening torque Nm AC input to UPS rectifier L1, L2, L3, N Check the tightening torque from the connector label.

  • Page 31: Ups System Interface Wiring Preparation

    3.2.3 UPS system interface wiring preparation Control wiring for features and options should be connected at the customer interface terminal blocks located on top front of the UPS, behind the door. DANGER Do not directly connect relay contacts to the mains related circuits. Reinforced insulation to the mains is required.

  • Page 32: Unpacking And Unloading The Ups

    Figure 3-3: UPS system 3.3 Unpacking and unloading the UPS If the equipment has been transported in the upright position the outside ’Tip&Tell’ indicator on the package surface should be intact. If the arrow has turned all blue, contact the appropriate parties for reporting inappropriate transportation.
  • Page 33 NOTE The UPS cabinet is heavy. If unpacking instructions are not closely followed, the cabinet may tip and cause serious injury. The UPS cabinet is bolted to a wooden pallet supported by wood skids. To remove the pallet, perform the following procedure: 1.

  • Page 34: Ups System Installation

    4 UPS system installation The customer has to supply the wiring to connect the UPS to the local power source. The electrical installation procedure is described in the following section. The installation inspection and the initial start-up of the UPS and installing an extra battery cabinet must be carried out by qualified service personnel such as a licensed service engineer from the manufacturer or from an agent authorized by the manufacturer.

  • Page 35: Battery System Installation

    FRONT VIEW REAR VIEW RIGHT SIDE VIEW Tunnel Tunnel DETAIL A BOTTOM VIEW DETAIL A Figure 4-1: Gland plate and connector locations 4.2 Battery system installation This UPS has internal batteries. Connection of these batteries is to be left to the responsibility of the commissioning personnel in order to avoid damages to the equipment or personal injuries in case of an incorrect connection.

  • Page 36: Installing Ups External Battery Cabinet And Battery Power Wiring

    4.3 Installing UPS external battery cabinet and battery power wiring For 93PM 50 kW UPS there are two different battery cabinet frames, EBC-S and EBC-L. Both of them are equipped with 36 batteries. External batteries are to be installed in parallel to internal ones for extending the back-up time of UPS-system.

  • Page 37: Figure 4-2: Battery Cabinet Through Holes

    Figure 4-2: Battery cabinet through holes P-164000249 30–50kW Revision 1 User's and Installation Guide...

  • Page 38: Figure 4-3: Ups Cabinet Through Holes

    Ø 63 Ø 63 M12 foot, Ø 60 4 pcs Figure 4-3: UPS cabinet through holes Mechanical lugs, located at the front of the cabinet, reduce installation time, and removable battery trays reduce battery maintenance time. A DC-rated circuit breaker within each cabinet provides protection and servicing isolation.

  • Page 39: Installing A Remote Epo Switch

    Connect the cables and signal wires to the UPS. If multiple cabinets are to be used repeat the steps to the rest of the cabinets and be sure to daisy chain the signal wire harnesses in the next cabinet. NOTE The battery cabinet is heavy.

  • Page 40: Installing Interface Connections

    4.5 Installing interface connections 93PM UPS contains a total of five (5) signal input connectors for customers which can be used for giving remote control commands to the UPS. Customer interface connector CN5 can be used for these purposes. Each input is a dry relay contact input and requires two wire signaling. None of the inputs are pre-programmed but need to be separately programmed by qualified service personnel.

  • Page 41: Battery Breaker Wiring Interface

    For Mini-slot accessories and communication devices selection see Chapter 6 Communication interfaces on page 39. For installation and setup of a Mini-Slot card, please contact your Eaton representative. To install wiring to connections: 1. If not already installed, install the LAN and telephone drops.

  • Page 42: Installation Of Options And Accessories

    5 Installation of options and accessories 5.1 Maintenance Bypass Switch (MBS) Maintenance Bypass Switch (MBS) is a UPS external device which is dedicated for providing a safe bypass path during UPS maintenance as well as providing power for the load during emergencies. The MBS is enclosed in its own separate panel cabinet.

  • Page 43: Figure 5-2: Three-Breaker Mbs Electrical Connection Drawing

    Figure 5-2: Three-breaker MBS electrical connection drawing 1. UPS input breaker 2. UPS output isolation switch 3. Maintenance bypass switch P-164000249 30–50kW Revision 1 User's and Installation Guide...

  • Page 44: Figure 5-3: Two-Breaker Mbs Mechanical Drawing

    Figure 5-3: Two-breaker MBS mechanical drawing 30–50kW P-164000249 User's and Installation Guide Revision 1...

  • Page 45: Figure 5-4: Three-Breaker Mbs Mechanical Drawing

    Figure 5-4: Three-breaker MBS mechanical drawing Installing the Maintenance Bypass Switch (MBS): Choose a location for the panel in the nearby the UPS and respective switchgear. Fasten the cabinet on the wall using a suitable method. Make sure that the complete UPS system is de-energized and safe to work. Depending on the selected product (three breakers or two breakers), continue below: •...
  • Page 46 b) Connect the cables between the cabinet terminal “UPS IN” and UPS rectifier terminals. c) Connect the jumper cables between UPS rectifier terminals and bypass terminals. d) Connect the cables between UPS output terminals and cabinet “UPS OUT” terminals. e) Connect the cables between cabinet “OUTPUT” terminals and switchgear. f) Connect the signal wiring between the cabinet and UPS signal input connector CN5 for MBS status and Module Output Breaker status.

  • Page 47: Communication Interfaces

    10. RS-232 port for service Figure 6-1: Communication interfaces 6.1 Mini-slot cards The Eaton 93PM UPS has three Mini-Slot communication bays. The UPS is compatible with the following Mini-Slot cards: • Network Card-MS Provides remote monitoring through a Web browser interface, e-mail, and a network management system (NMS) using SNMP and connects to a twisted-pair Ethernet (10/100BaseT) network.

  • Page 48: Figure 6-2: Network Card-Ms

    Figure 6-2: Network Card-MS • PX Gateway Card Provides remote monitoring through a Web browser interface, e-mail, and a network management system (NMS) using SNMP and connects to a twisted-pair Ethernet (10/100BaseT) network. The card also provides direct integration of UPS information (meters and status) to a Building Management System (BMS) using the Modbus RTU and TCP protocols.

  • Page 49: Intelligent Power Software

    Power Protector (IPP) application provides automatic, graceful shutdown of computers and virtual machines or servers powered by an Eaton UPS during a power outage that lasts longer than your available battery runtime. Intelligent Power Protector can be remotely supervised and managed by the Intelligent Power Manager (IPM) application.

  • Page 50: Signal Input Monitoring

    The Intelligent Power Software is delivered on a CD with the UPS. Alternatively, you can download it from the Eaton web page. 6.3 Signal input monitoring This standard feature lets you connect the UPS to your signal inputs, such as smoke detectors or overtemperature alarms.

  • Page 51: Ups Operating Instructions

    Before operating the UPS, confirm the UPS nominal voltage and frequency from display by selecting Settings > Info. If the UPS need to be operated with another voltage or frequency, contact your closest Eaton office or Eaton authorized partner. NOTE The UPS in not a measuring device.

  • Page 52: Status Indicators

    Figure 7-1: Parts of the display The display consists of the following parts: • A: Status bar The status bar displays the UPS name, state, current date and time, meters information, and a sign in/out button. Active alarms and warnings are also shown. •...

  • Page 53: System Events

    Indicator Status Description Green The UPS is operating normally and supplying power to the critical load. The UPS is turned off. Figure 7-2: Green symbol Yellow The UPS is in Battery mode. Because Battery mode is a normal condition of the UPS, the Normal indicator also remains illuminated.

  • Page 54: Steps To Operate The Ups

    This message is also written to the Active Events log. Some notices and alarms may be accompanied by an audible horn. To silence the horn, press any button once. 7.2 Steps to operate the UPS The table below shows the menu structure of the 93PM UPS. Main menu Submenu...

  • Page 55: Signing In

    Main menu Submenu Functions System log A log of all system events. Service log A detailed log of UPS operations. Change log A log of all changed settings and their values. Statistics Statistics summary A summary of UPS statistics. Statistics details Details are available by pressing on different statistics.

  • Page 56: Starting The Ups In Double Conversion Mode

    7.4 Starting the UPS in double conversion mode To start the UPS system: Unfasten the front door latch and swing the door open. Verify that rectifier input switch S1 and battery breaker are closed, and close the front door. Close the UPS input feeder circuit breaker. Close the UPS bypass input feeder circuit breaker.

  • Page 57: Starting The Upms

    7.6 Starting the UPMs Make sure that load level does not exceed single UPM capacity. To start an individual power module in double conversion mode: Unfasten the front door latch and swing the door open. Verify that rectifier input switch S1 and battery breaker CB1 are closed, and close the front door.

  • Page 58: Transfer From Bypass To Double Conversion Mode

    Mode Note that the Energy Saver mode commands are displayed only if enabled at the factory or by an Eaton Customer Service Engineer. To transfer the critical load to Energy Saver mode: Press the Controls button in the main menu.

  • Page 59: Ups And Critical Load Shutdown

    The UPS transfers to Battery mode and then to Double conversion mode. If the power module is not available, the system remains on bypass and an alarm sounds. The NORMAL status indicator is illuminated. The UPS status indicates UNIT ONLINE. The UPM status indicates ACTIVE. 7.11 UPS and critical load shutdown To perform maintenance or service on the critical load, shut down power to the load by performing the following procedure:...

  • Page 60: Upm Shutdown

    You should use this feature only when you want to de-energize the critical load. NOTE The following instructions are for the Eaton Corporation-supplied EPO switch. If a customer- supplied EPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch.

  • Page 61: Turning Ups From Double Conversion Mode To Mechanical Bypass

    To use the EPO switch: Press the EPO pushbutton switch. The input, output, and bypass backfeed relays open, the battery breaker or disconnect is tripped, and the power module is turned off immediately, without asking for verification. DANGER Do not attempt to restart the system after Load Off until the cause of the shutdown has been identified and cleared.

  • Page 62: Turning Ups From Mechanical Bypass To Double Conversion Mode

    Turn the MBS from UPS position to Bypass position. Perform the LOAD OFF procedure in Chapter 7.11 UPS and critical load shutdown on page Turn OFF the rectifier switch to disconnect UPS rectifier input. Turn OFF the Static bypass switch to disconnect UPS bypass input. UPS is now in the mechanical bypass mode: Figure 7-7: Mechanical bypass mode 7.17 Turning UPS from mechanical bypass to double...

  • Page 63: Figure 7-9: Double Conversion Mode

    The UPS is now in double conversion mode: Maintenance Bypass Switch (MBS) Figure 7-9: Double conversion mode P-164000249 30–50kW Revision 1 User's and Installation Guide...

  • Page 64: Ups Maintenance

    8 UPS maintenance The components inside the UPS cabinet are secured to a sturdy metal frame. All repairable parts and assemblies are located for easy removal, with very little disassembly. This design allows authorized service personnel to perform routine maintenance and servicing quickly. You must schedule periodic performance checks of your UPS system to keep it running properly.

  • Page 65: Performing Preventive Maintenance

    8.2 Performing preventive maintenance The UPS system requires very little preventive maintenance. However, the system should be inspected periodically to verify that the units are operating normally and that the batteries are in good condition. 8.2.1 DAILY maintenance Perform the following steps daily: 1.

  • Page 66: Battery Maintenance

    8.2.5 BATTERY maintenance Contact your service representative for battery maintenance. Battery replacement and maintenance should be performed only by authorized service personnel. 8.3 Recycling the used UPS or batteries Before scrapping UPS or its battery cabinet, the battery bank must be removed. Local requirements must be followed in battery recycling or discard.

  • Page 67: Maintenance Training

    8.4 Maintenance training For more information about training and other services, contact your Eaton representative. P-164000249 30–50kW Revision 1 User's and Installation Guide...

  • Page 68: Technical Data

    9 Technical data 9.1 Standards Safety: IEC 62040-1, IEC 60950-1 EMC, Emissions: IEC 62040-2/Ed.2 EMC, Immunity: IEC 61000-2-2 (Low-frequency conducted) IEC 61000-4-2 (ESD) IEC 61000-4-3 (RF electromagnetic field) IEC 61000-4-4 (Fast transient-burst) IEC 61000-4-5 (Surge) IEC 61000-4-6 (Conducted RF common mode) IEC 61000-4-8 (Power frequency magnetic field) Performance &...

  • Page 69: Ups System Input

    200W (250A) Table 9-3: External Battery Cabinet Full list of different UPS models and accessories covered by this user manual is available by contacting local Eaton sales office or representative. 9.3 UPS system input Rated input voltage 220/380V; 230/400 V; 240/415 V...

  • Page 70: Ups System Output

    Input power factor 0,99 Rated mains input current 30kW: 48 A (380 V), 46 A (400 V), 44 A (415 V) 40kW: 64 A (380 V), 61 A (400 V), 58 A (415 V) 50kW: 80 A (380 V), 76 A (400 V), 73 A (415 V) Maximum mains input current 95 A Input current distortion at rated input current, iTHD...

  • Page 71: Table 9-5: Ups System Output

    Rated output frequency 50 or 60 Hz, configurable Output frequency variation ± 0,1 Hz Slew rate 1 Hz/s Maximum frequency range for synchronization with bypass ± 4 Hz as default. User settable 0,5 to 5 Hz. Maximum synchronized phase error <...

  • Page 72: Battery

    9.5 Battery Battery type VRLA Battery quantity 36 blocks, 216 cells per battery string, max 6 strings Battery voltage 432 V Recharge profile ABM or float, constant voltage with settable current limit Charge current limit 22 A Battery start option Table 9-6: Battery 9.6 External battery connection Battery type...

  • Page 73: Ups Environmental Specifications

    9.7 UPS environmental specifications Acoustic noise at 1 m 55 dB at 75% load, 60 dB at 100% load Ambient UPS storage temperature range -25 °C to + 55 °C in the protective package* Ambient service temperature range, (UPS) + 5 °C to + 40 °C* Relative humidity range 5 to 95%, no condensation allowed Maximum service altitude...

  • Page 74: Warranty

    The warranty is only valid if the installation inspection and initial start up of the UPS unit is carried out by a service engineer approved by Eaton. Service and maintenance of the UPS shall also be performed only by a service engineer approved by Eaton. Otherwise the warranty will be voided.

  • Page 75: Installation Checklist

    11 Installation checklist All packing materials and restraints have been removed from each cabinet. Each cabinet in the UPS system is placed in its installed location. A cabinet grounding/mounting kit is installed between any cabinets that are bolted together. All conduits and cables are properly routed to the UPS and any ancillary cabinets. All power cables are properly sized and terminated.
  • Page 76 A remote battery disconnect control is mounted in its installed location and its wiring is terminated inside the UPS and battery cabinet. (OPTIONAL) Accessories are mounted in installed locations and wiring is terminated inside the UPS cabinet. (OPTIONAL) Startup and operational checks are performed by an authorized Eaton Customer Service Engineer. 30–50kW P-164000249...

  • Page 77: Appendix A: User Settings

    12 APPENDIX A: User settings The UPS has the following settings that are user modifiable. In the Home screen, select Settings. User settings: Setting Description Info Information on the UPS model, including part number and serial number. About Version information. Table 12-1: User settings To modify the Config settings, you need to sign in.
