OSD Menu and Function

The complete OSD Menu is shown in the table below. The Main Menu icon for each menu group
is shaded, and the individual functions within the group follow. To access the OSD Menu, push
the MENU button.Use the ENTER button to select a highlighted menu, and to move between
individual items within a menu. Use the UP/DOWN buttons to select/deselect an item, or to
increase/decrease the value of an item.
Contrast and Brightness
Contrast
Brightness
Video Adjustment
Auto Adjust
Left/Right
Up/Down
Horizontal Size
Fine
OSD Tool
OSD Left/Right
OSD Up/Down
OSD Timeout
Factory Reset
OSD Language
Color Adjustment
Audio Adjustment
Volume
Mute ON/OFF
Auto DIM
Auto Dim
Dimming Range
Hog iPC Handbook
Controls the display contrast.
Controls the display brightness.
Automatically sets display image size, position, and fine adjustment. Contrast
and brightness are not adjusted.
Controls horizontal position.
Controls vertical position.
Increases or decreases the horizontal size of the image.
Controls the vertical fine adjustment. May improve picture detail in emulation
modes.
Adjusts the default horizontal position of the OSD on the display.
Adjusts the default vertical position of the OSD on the display.
Determines time (in seconds) that OSD waits before automatically closing after
no action has been performed.
Recalls original factory settings of image parameters.
Selects the OSD menu language—English, French, German, Italian, Spanish,
Japanese, Traditional Chinese, or Simplified Chinese.
Adjusts preset color temperature of the image. Available choices are 9300,
7500, 6500, and 5500° Kelvin (K). A User mode allows custom setup of each
color component of the image—Red, Green and Blue. Default setup for this
parameter is 6500°K. Do not adjust color temperature unless you have a specific
need to do so.
Adjusts the loudspeaker volume.
Mute ON turns off the audio function. Mute OFF restores the audio function.
Turns the Auto-Sensing Brightness Adjustment circuit ON or OFF.
Menu shows sensed light level, and brightness setting as a percentage of full
scale (same setting as Brightness in Contrast and Brightness menu when Auto
DIM is OFF). With Auto DIM ON, brightness is now controlled by the light sensor
located at top center of the front bezel. See additional discussion of the Auto-
Sensing Brightness Adjustment feature further in this section.
