Christie Roadster S+14K-J User Manual
  1. Manuals
  2. Brands
  3. Christie Manuals
  4. Projector
  5. Roadster S+14K-J
  6. User manual

Christie Roadster S+14K-J User Manual

2.0, 2.4, and 3.0kw j series
Hide thumbs Also See for Roadster S+14K-J:
Table of Contents

Advertisement

Quick Links

J Series
2.0, 2.4, and 3.0kW
U s e r M a n u a l
020-100707-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Roadster S+14K-J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Christie Roadster S+14K-J

Summary of Contents for Christie Roadster S+14K-J

  • Page 1 J Series 2.0, 2.4, and 3.0kW U s e r M a n u a l 020-100707-01...
  • Page 3 J Series 2.0, 2.4, and 3.0kW U s e r M a n u a l 020-100707-01...
  • Page 4 Projector lamps (See Christie separate lamp program policy). c. Damage caused by use of a projector lamp beyond the recommended lamp life, or use of a lamp supplied by a supplier other than Christie. d. Problems caused by combination of the product with non-Christie equipment, such as distribution systems, cameras, video tape recorders, etc., or use of the product with any non-Christie interface device.

  • Page 5: Table Of Contents

    Table of Contents 1: Introduction 1.1 Labels and Marking ........................1-1 1.2 Purchase Record and Service Contacts ..................1-2 1.3 Projector Overview........................1-3 1.3.1 How the Projector Works ....................1-3 1.3.2 User Interface Overview ......................1-3 1.3.3 List of Components......................1-3 1.3.4 Key Features ........................1-4 1.4 Safety Warnings and Guidelines ....................1-5 1.4.1 General Precautions ......................1-5 1.4.2 AC /Power Precautions......................1-6 1.4.3 Lamp Precautions ........................1-6...
  • Page 6 Table of Contents 3.12 Using Multiple Projectors ......................3-54 3.13 Remote Control of the Projector ....................3-57 3.14 Alarms ............................3-58 4: Web User Interface 4.1 Logging On ..........................4-1 4.2 Navigating the Web User Interface..................... 4-2 4.2.1 Help Text..........................4-2 4.3 Basic Operation...........................
  • Page 7 Table of Contents 6.7 Displays ............................6-3 6.7.1 The projector is on but there is no display................6-3 6.7.2 Severe Motion Artifacts.......................6-3 6.7.3 Image Appears ‘Squeezed’ or Vertically Stretched into Center of Screen......6-4 6.7.4 The Display is Jittery or Unstable..................6-4 6.7.5 The Display is Faint......................6-4 6.7.6 The Upper Portion of the Display is Waving, Tearing or Jittering........6-4 6.7.7 Portions of the Display are Cut Off or Warped to the Opposite edge .........6-4 6.7.8 Display Appears Compressed (Vertically Stretched) ............6-4...
  • Page 8 Table of Contents 7.4.1 Analog (Only) Input......................7-6 7.4.2 Twin HDMI Input ....................... 7-6 7.4.3 Dual Link DVI Input......................7-7 7.4.4 Video Decoder Input ......................7-7 7.4.5 Dual 3G/HD/SD - SDI Input....................7-7 7.5 Control Signal Compatibility ..................... 7-7 7.5.1 Projector Control......................... 7-7 7.5.2 Control Receiver .........................

  • Page 9: Labels And Marking

    Such users may also be trained to replace the lamp and air filter, but cannot install the projector or perform any service functions on the J Series projector. SERVICE: Only Christie accredited technicians knowledgeable about all potential hazards associated with high voltage, ultraviolet exposure and high temperatures generated by the lamp and associated circuits are authorized to 1) assemble/install the projector and 2) perform service functions inside the projector.

  • Page 10: Purchase Record And Service Contacts

    In most cases, servicing is performed on site. If you have purchased the projector, fill out the information below and keep with your records. Table 1.1 Dealer: Dealer or Christie Sales/Service Contact Phone Number: Projector Serial Number*: Purchase Date: Installation Date: * The serial number can be found on the license label located on the back of the projector.

  • Page 11: Projector Overview

    OSD display, and provide a quickly accessible interface to view error reporting. The functions on the OSD can also be controlled using the Christie Serial Protocol, via a serial or Ethernet connection to the projector. The Web interface provides access to the menu system as a Virtual OSD (On-screen display) and to features that maintain the projector software and settings.

  • Page 12: Key Features

    • Four input slots for Optional Input Modules Refer to Section 7 Specifications for a complete list of technical specifications. Table 1.3 J Series Projectors Model Name Part Number Roadster S+14K-J 132-010113-XX Roadster HD14K-J 132-011114-XX Roadster S+18K-J 132-013116-XX Roadster HD16K-J...

  • Page 13: Safety Warnings And Guidelines

    Position all cables where they cannot contact hot surfaces or be pulled or tripped over. All installation and maintenance procedures must be performed by a Christie accredited service technician. Projector must be operated in an environment that meets operating specifications, as...

  • Page 14: Ac /Power Precautions

    Section 1: Introduction 1.4.2 AC /Power Precautions Use only the AC power cord supplied. Do not attempt operation if the AC supply and cord are not within the specified voltage and power range. Refer to the license label Section 7 Specifications on the back of the projector or for rated voltage and power.

  • Page 15: 2: Installation And Setup

    2 Installation and Setup This section explains how to install, connect and optimize the projector for delivery of superior image quality. Illustrations are graphical representations only and are provided to enhance the understanding of the written material. Projector Quick Setup and Installation The following instructions are for those preferring a quick setup.
  • Page 16 Section 2: Installation and Setup 2. Align the lens interface plate with the lens mount. Align the lens electrical connector with the mating connector on the lens mount. Fully insert the assembly straight into the lens mount opening without turning. Press using your hand as shown in Figure 2-2.
  • Page 17 Section 2: Installation and Setup IGURE 6. Use a 5mm hex driver to fasten the red security screws provided with the lens mount (Figure 2-4), or hand tighten the lens retaining screws attached to the lens. NOTES: 1) Recommended for heaviest lenses such as 0.73:1 and 1.2:1.
  • Page 18 Section 2: Installation and Setup • Video Decoder Input Card, depending on the source you can apply the following; • Composite video source to 1-CVBS, using a BNC Cable Same signal can be used on 4, 5 or 6 when NOTE: input is selected as CVBS.
  • Page 19 Section 2: Installation and Setup For 3000W Model 1. Remove the locking pin from the bracket surrounding the AC receptacle at the AC inlet of the projector by pressing down on the button on the end of the locking pin, and then pull upwards on the pin to remove it, as shown in Figure 2-6.
  • Page 20 Section 2: Installation and Setup 3. Insert the plug fully on to the receptacle. When fully inserted, the cap on the AC plug will rest against the side of the projector (Figure 2-8). 4. Reinsert the locking pin into the bracket surrounding the AC receptacle by pressing down on the button on the end of the locking pin and insert the pin into the bracket, as shown in Figure 2-8.

  • Page 21: Detailed Setup And Installation

    Section 2: Installation and Setup STEP 6 - Selecting a Source Press one of the input keys on the remote or built-in keypad to select and display the image for the source you connected in Step 3. STEP 7- Adjusting Image Adjust the image settings, such as Brightness, Contrast, Gamma, Focus, Zoom, etc.
  • Page 22 Section 2: Installation and Setup 2-10 F IGURE RONT RIENTATION Built-in Keypad The built-in keypad is located at the rear of the projector. Use it similarly to the IR remote to control the projector. An LCD display is located above the keypad for displaying projector status. AC Receptacle The AC receptacle is located at the back of the projector.
  • Page 23 Section 2: Installation and Setup Cooling and Air Vents Adequate airflow through the projector will prevent it from overheating. Keep all projector vents unobstructed and ensure adequate airflow around the projector. See Figure 2-11. Allow at least 1 meter or more of space between the projector and a wall or other structure and place it on a platform that does not extend...

  • Page 24: Installation Considerations

    Section 2: Installation and Setup • Zoom and Focus – There are two internal lens motors that allow for quick motorized adjustment of zoom and focus. Adjust zoom to fit the displayed image on the screen and adjust focus to improve the clarity of the image.
  • Page 25 Section 2: Installation and Setup 2-12 IGURE Rules for all hoisting: • Use at least 4 rigging points for hoisting up to 3 projectors. • Connect safety cables, and rigging equipment suitable to your application such as clamps, cables, eyebolts, or straps, which accommodate the load rating.

  • Page 26: Hoisting Procedure

    Section 2: Installation and Setup IMPORTANT! Remove the lens before hoisting the projector. 2-14 NEVER IGURE ANDLES FOR OISTING OR AFETY OINTS 2.2.3 Hoisting Procedure This procedure applies to one or more projectors. To hoist a stack, first stack 2 or 3 projectors according to the stacking procedure included in this manual.

  • Page 27: Stacking Procedure

    Secure a maximum of 3 projectors with the stacking mounts as described below. Do not stack more than 3 projectors. Christie stacking hardware required. The top projector could slide off and cause injury or death.
  • Page 28 Section 2: Installation and Setup 1. Position the projectors. • Place each projector to be stacked on a secure table or cart. • Place 1 projector on its side to access its adjust- able feet, and stacking legs (Figure 2-17). •...
  • Page 29 Section 2: Installation and Setup 4. Loosen the rear stacking leg nuts On the rear stacking legs (Figure 2-19), loosen the nuts so the legs have some lateral movement for easier alignment with the stacking mounts on the other projector. •...

  • Page 30: Alignment Procedure

    Section 2: Installation and Setup Critical Safety Procedure. At each of the 3 stacking points, insert the safety pin fully through the holes in the stacking mounts and stacking legs (Figure 2-21). Ensure that each pin is fully inserted to engage the safety lock and secure the projectors together.
  • Page 31 Section 2: Installation and Setup 5. Align the center lines of the grid. Turn the 2 rear stacking mount wheels to move the top projector as necessary to achieve well-aligned center lines. Use a screwdriver in the holes around the rim of each adjusting wheel for better leverage and control.

  • Page 32: Types Of Installations

    Section 2: Installation and Setup 7. Secure all stacking wheels and leg nuts Critical Safety Procedure • Turn all 3 stacking wheels until they are firmly secure against the rest of the stacking mount. See Figure 2-25. • Secure both 2 rear leg nuts against the bottom of the projector. 8.
  • Page 33 Section 2: Installation and Setup Front Screen Installations In front screen installations, the projector and audience are positioned in front of the screen, which can be flat or curved. Flat screens offer a gain of about 1.0 with a viewing angle just less than 180°. This type of screen reflects incident light equally in all directions so the audience can see the display from various angles.
  • Page 34 Section 2: Installation and Setup Rear Screen Installations There are two basic types of rear screens: diffused and optical. A diffused screen has a surface which spreads the light striking it. Purely diffused screens have a gain of less than 1.0. The advantage of the diffused screen is its wide viewing angle, similar to that of a flat screen for front screen projection.

  • Page 35: Projector Position And Mounting

    Use the lens and screen size to calculate the precise throw distance using the tables provided IMPORTANT! in the Dealer Section of the Christie Website, PN 020-100221-XX. Due to lens manufacturing tolerances for lens focal length, actual throw distance can vary 5% between ±...
  • Page 36 Section 2: Installation and Setup Table 2.1 WUXGA Vertical Offset Ranges WUXGA Lens Description Lens Part Number Minimum Offset Above or Below Lens Center Lens ILS 0.73:1SX+/0.67:1HD 118-100110-XX ±22% ±132 pixels Lens ILS 1.25-1.6SX+/1.16-1.49HD 118-100111-XX ±82% ±492 pixels ALL OTHER LENSES ±112% ±672 pixels Table 2.2 HD 1080p Vertical Offset Ranges...
  • Page 37 Section 2: Installation and Setup Table 2.4 WUXGA Horizontal Offset Ranges WUXGA Lens Description Lens Part Number Minimum Offset Above or Below Lens Center Lens ILS 0.73SX+/0.67HD 118-100110-XX ±6% ±58 pixels Lens ILS 1.25-1.6SX+/1.16-1.49HD 118-100111-XX ±38% ±365 pixels ALL OTHER LENSES ±54% ±518 pixels Table 2.5 HD 1080p Horizontal Offset Ranges...
  • Page 38 Section 2: Installation and Setup 2-29 IGURE 2-24 J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev. 1 (10-2011)

  • Page 39: Mounting

    For more information, contact your dealer. Use only the Christie approved ceiling mount kit designed for your projector. Refer to the installation instructions and safety guidelines provided in the kit.

  • Page 40: Adjusting Projector Height/Tilt

    Section 2: Installation and Setup 2.3.3 Adjusting Projector Height/Tilt Adjusting Height You can modify the height of the projector to remedy a slightly uneven mounting surface by adjusting the four feet threaded into the bottom chassis. Turn each foot clock-wise or counter-clockwise until the projector is level on all sides.

  • Page 41: Advanced Optical Alignment

    Section 2: Installation and Setup 4. If necessary, center the image on the screen: If the projector is mounted off center to the screen axis, then offset the lens as much as required. Aim the projector over slightly towards the center of the screen, but use caution when doing so, as too much tilt will cause excessive keystone distortion.
  • Page 42 Section 2: Installation and Setup 3. If boresight is required, refer to Figure 2-34 Cross-Hair Pattern to understand how the adjustment screws on the lens mount affect the corresponding cross-hairs on the test pattern. The capscrew, (Figure 2- NOTE: 35) may be under a plastic cap, remove and retain before adjusting. 4.

  • Page 43: Powering Down

    Section 2: Installation and Setup 11. Lock the setscrews, and re-check the boresight quality. Tighten the setscrew enough to ensure they will not shift. 2-36 IGURE 2.3.6 Powering Down The projector can be powered down by using one of the following methods: Remote Keypad/Built-In Keypad •...

  • Page 44: Connecting Communications

    Section 3 Operation,3.8.7COMMUNICATIONS - Submenu the Serial Command document provided in the Dealer Section of the Christie Website, PN 020-100224-XX. Connecting RS-232 Two nine-pin D-sub connectors, labeled RS-232 IN and RS-232 OUT on the input panel, are dedicated to...
  • Page 45 Refer to Section 3 Operation for further information about setting up and using a projector connected via Ethernet, and the Serial Command document provided in the Dealer Section of the Christie Website, PN 020- 100224-XX. Connecting Multiple Projectors To connect multiple projectors in a network with serial communication: RS-232 NETWORK: 1.
  • Page 46 Section 2: Installation and Setup : To control multiple projectors with a computer/controller having an RS-422 interface: MIXED NETWORK 1. Set them all to the same baud rate as your RS-422 controller. You must enable this combination of NOTE: RS-422 and RS-232 in the Communications menu. Set the “Network Routing” option to “RS-232 and RS-422 Joined”, see Section 4 Web User Interface.
  • Page 47 Section 2: Installation and Setup 2-42 E IGURE THERNET ETWORK ETUP : See Section 3.8 Configuration - SETTING THE PROJECTOR IP ADDRESS, SUBNET MASK AND GATEWAY Adjusting System Parameters and Advanced Controls. Includes settings for configuring the IP address via HDCP (factory ETHERNET/COMMUNICATION SETTINGS: default) or static.
  • Page 48 Section 2: Installation and Setup 2-43 J IGURE OINING ETWORKS To isolate just RS-422 communications, select “RS-232 and Ethernet Joined”. In Figure Figure 2-43 Joining Networks, only projector #1 will respond to the RS-422 controller. To isolate just Ethernet communications, select “RS-232 and RS-422 Joined”—only projector #1 will respond via Ethernet.

  • Page 49: Projector Communications

    Section 2: Installation and Setup 2.3.8 Projector Communications Status LEDs Looking from the back of the projector, the LEDs represent, from left to right; Lamp, Comm, Status, and Shutter. The LEDs will display the colors as shown below: Status LEDs LED State Lamp Off - lamp off...

  • Page 50: Connecting Sources

    Section 2: Installation and Setup Connecting Sources Sources are connected to the Input Panel located at the back of the projector. Figure 2-44 Input Panel. The Input Panel allows one image processor board and up to 4 input cards to be inserted. The input cards are hot swappable i.e.
  • Page 51 Section 2: Installation and Setup Analog BNC Input Card This card accepts several types of sync modes. In 5-wire sync mode all 5 BNC connectors are used. If H and V connectors are swapped, this card will still operate normally. An analog graphic source such as a VGA from a PC can be connected.
  • Page 52 Section 2: Installation and Setup Video Decoder Input Card This card accepts and decodes standard definition (SD) video. This includes CVBS (composite video), S- Video, and component sources. This card supports as many as 6 video signals, four of them on BNC connectors and two on 4-pin mini-DIN connectors.
  • Page 53 2-45 U IGURE SE OF ISTRIBUTION Christie loop-through may be used to set up a tiling array (Figure 2-45 Figure 2-50). The system allows wiring providing the HDCP requirement is met when HDCP is used by the source. The cascade level of devices can be no more than 7 levels deep.
  • Page 54 Section 2: Installation and Setup • Balance the connection tree to ensure the level of loop-through is minimized. This is to enable the NOTE: downstream projectors to finish source switches in a minimum amount of time. (Applicable to arrays with HDCP only) 2-46 1 IGURE...
  • Page 55 Section 2: Installation and Setup 2-49 2 IGURE INGLE WIRING LOOP THROUGH NO PIP IS SUPPORTED 2-50 3 IGURE THROUGH WIRING SOLUTION J Series 2.0, 2.4, and 3.0kW User Manual 2-41 020-100707-01 Rev. 1 (10-2011)

  • Page 57: Operating The Projector

    3 Operation This section describes the controls and switches used for basic projector operation once it is properly installed, aligned and configured by a Christie accredited service technician. Section 5 Maintenance. Refer to Safety Warnings and Guidelines in Operating the Projector Control the projector using one of the following options: •...
  • Page 58 Section 3: Operation Remote Keypad 3-1 R IGURE EMOTE EYPAD J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev. 1 (10-2011)
  • Page 59 Section 3: Operation Wired Remote You can convert the remote keypad into a wired remote keypad using the cable provided with the projector. Connect one end into the remote and the other to the XLR connector on the input panel labeled as wired keypad.

  • Page 60: Remote Keypad Commands

    Section 3: Operation • Power Key, used to switch from Standby mode to ON, and from ON to Standby mode; LED always remains Amber • Help Key, only available in the On Screen Display (OSD) context; LED is Amber when the menu is being displayed on the projected image display;...
  • Page 61 Section 3: Operation Channel Select a specific source setup (channel) defined and stored in projector memory. Once you enter a two-digit channel number (or, if there is a list displayed, highlight it and press E ), the display will automatically NTER change and update according to the numerous setup parameters defined for that channel.
  • Page 62 Section 3: Operation Number Keys Press 1 to 9 to enter a value in a text box or to select a menu item. Press 0 before pressing another number to enter a number greater than 9, e.g. press 0 then 2 to enter the number 12 as a menu selection.
  • Page 63 Section 3: Operation IF WITHIN A PRESENTATION: Press F followed by two numeric numbers to enable a specific color or colors in the display (see right). For example, will display only red, and will display green data. Eliminating one or more colors can help with certain diagnostics and setups, such as when accurately overlaying one image on top of another from stacked projectors.

  • Page 64: Navigating The Menus

    Section 3: Operation Lens H and Lens V When adjusting the image for focus, zoom or horizontal and vertical positioning, use the specific arrow keys or U ) related to each function. A small window will appear to IGHT RROW RROW indicate the type of adjustment taking place.
  • Page 65 Section 3: Operation When finished with a function menu: • Press E to return to the previous screen. • Press M to leave the menu system and return to the presentation. If there is no signal present, all source-dependent adjustments are disabled. After 15 minutes of NOTES: 1) inactivity, the projector leaves the menu system and returns to the presentation.
  • Page 66 Section 3: Operation Slide bars in menus – The current value for a given parameter, such as size or vertical stretch, appears to the left of its slide bar icon (adjustment window). This number often expresses a percentage, or it may have units associated with it (such as pixels), depending on the specific option.
  • Page 67 Section 3: Operation Editing Text Activate the Edit Window: To enter or edit text, highlight the desired parameter (such as a channel name) and press E to activate its adjacent edit window. Any previously entered text is displayed with its first NTER character highlighted in a square cursor, signifying that this character is ready for editing.

  • Page 68: Using Inputs And Channels

    Section 3: Operation Edit numerical values: Enter numbers directly from the keypad to specify numbers representing projectors channels (source setups), or slots. As each digit is entered, it is inserted on the right of the field, and the numbers already in the field are shifted on the left.
  • Page 69 Section 3: Operation 3. Use the following menu options to select the source of the image for the main or PIP/Secondary image. - menu options Menu > Input Switching & PIP > Main Input and Menu > Input Switching & PIP >...

  • Page 70: Channel Setup Menu

    Section 3: Operation Channel Setup Menu All available channels are listed in the Channel Setup menu, which describes how each channel can be accessed and provides access for editing, copying and deleting channels. Press M from the presentation level to display the Main menu. To display the Channel Setup menu, press 3, or move the highlight to the Channel Setup option and press E .
  • Page 71 Section 3: Operation Table 3.1 - Abbreviations for Signal Type The first 5 items in this table are analog RGB with various sync combinations indicating Sync Source when editing the channel: Abbrev. Signal Type No Sync Composite (4 wire) on HC input Composite (4 wire) on V input Sync-on-green (4 wire) Separate H,V (5-wire)
  • Page 72 Section 3: Operation TO DELETE A CHANNEL, highlight the desired channel in the Channel Setup menu, then press E NTER activate the Select Channel Operation submenu. Select Delete and press E —a window will appear to NTER confirm the deletion of this channel. 3-15 D IGURE ELETE A...

  • Page 73: Adjusting The Image

    Section 3: Operation CHANNEL EDIT — STEP 3 If desired, review and/or edit the following channel setups in the Channel Edit menu: • NAME An alphanumeric label can be defined and/or changed here. Channel names can be up to 12 characters in length.

  • Page 74: Size And Position Menu

    Section 3: Operation From your presentation, you can access any of the individual options in these menus by pressing M followed by the appropriate two-digit number representing their location in the menu system. For example, press M 24 to quickly access the “Color Space” option in the Image Settings menu. For certain options, preference may be to use a “direct key”...
  • Page 75 Section 3: Operation RESIZE PRESETS The same resize presets are available to all HD and SXGA+ screen models. However, the graphics NOTE: used to describe each preset in this section are of the SXGA+ models only. Resize Presets will display an image in its native resolution (no resizing) or will resize the image by maximizing either the height, width or both height and width, or will resize to the maximum...
  • Page 76 Section 3: Operation 3-20 N IGURE ESIZING FULL SIZE - uses all pixels for displaying the image, regardless of source or original aspect ratio. Incoming source material having a different aspect ratio than the projector will be stretched for display. 3-21 F IGURE FULL WIDTH - fills the projector display from left-to-right...
  • Page 77 Section 3: Operation ANAMORPHIC - displays an anamorphic image in its native 16:9 aspect ratio. The image will fill the screen from side-to-side and be centered between black bars at top and bottom. SIZE Controls both the image width and height in tandem, maintaining the current aspect ratio of the displayed signal data.
  • Page 78 Section 3: Operation KEEP ASPECT ON AUTO SETUP Ensures that auto setup for any source will maintain the input aspect ratio when the default size is calculated. NTSC and PAL formats always keep aspect ratio during auto setup regardless of the Keep Aspect on Auto Setup control.

  • Page 79: Image Settings Menu

    Section 3: Operation Image Settings Menu Use the Image Settings menu to alter your main image without affecting its size or position. Changes made are applied immediately and are saved when you exit the menu (press E ). Options not available for the projector model or source are disabled and appear dim (grey).
  • Page 80 Section 3: Operation • VIDEO STANDARD The projector automatically detects the incoming horizontal and vertical frequencies and sets the projector processing of this signal to the corresponding standard. The current video standard name appears in the Video Options submenu, and includes an “A” if it is auto-detected. Press E to view or select a different video NTER standard from those available to the projector—any that are disabled have frequency characteristics that differ...
  • Page 81 Section 3: Operation • FILM MODE DETECT Enables or disables film motion detection. Film mode detect is a control that you will not need to adjust. The image processor automatically detects the type of input for most types of interlaced signals. i.e. 3:2, 2:2. However, there are cases where progressive segmented frame signals (PsF, a broadcast Sony standard) are not detected properly.
  • Page 82 Section 3: Operation Good RGB or input levels—that is, the drives and black levels for each of the three colors, red, green and blue—ensure that images from analog sources other than decoded video have maximum contrast without crushing black or white. By default (and in an “Auto Setup”), the projector automatically determines the best input levels by monitoring image content and adjusting the controls appropriately—further adjustment is typically not required to obtain proper blacks or whites.
  • Page 83 Section 3: Operation • CLAMP LOCATION Brightens the image produced from certain high-resolution high-frequency graphic sources. The projector automatically selects the best clamp location for most sources. Use the normal Back Porch location if the image is either sufficiently bright or overly bright. Select Sync Tip if the image appears unusually dim, if there are horizontal streaks across the image, or if there is significant color drift.
  • Page 84 Section 3: Operation 3-28 A IGURE DJUSTING NPUT EVELS SING THE ETECTOR (RED EXAMPLE SHOWN) • COLOR ENABLE Select which color or colors you want to see in the display, useful while working with color temperature white levels or input levels. Input levels apply for the current source only, but for any color temperature NOTES: 1) used.
  • Page 85 Section 3: Operation The 2.22 curve is a power curve typically used to encode graphics and video sources, see Figure 3-29 Gamma Curve. The 'standard' curve (auto setup default) is a modified 2.22 curve with a small linear section in the black that enhances the detail in darker areas of the projected content.
  • Page 86 Section 3: Operation NOISE REDUCTION SETTINGS - Submenu • NOISE REDUCTION Selects a filter sensitivity to noise. A higher value may improve noisy sources, but it will soften the image. • BLOCK ARTIFACT REDUCTION Locates and reduces block edges produced by discrete cosine transform (DCT) based compression processing. •...

  • Page 87: Configuration - Adjusting System Parameters And Advanced Controls

    Section 3: Operation Optical Aperture The optical aperture inside the projector controls the diameter of the light beam passing through the system. With a fully open aperture (slidebar default of "0"), the maximum amount of light passes through for maximum brightness in your images. Increase the slidebar setting to reduce the aperture diameter and maximize contrast ratio instead.
  • Page 88 The OSD NOTE: only allows the fade time to be set. To initiate a Fade to Black, the Christie Serial command should be used. • HDMI OUTPUT LOOP SOURCE This control is used to configure the HDMI output options. Selecting Direct Loop will directly pass-through the HDMI input signals: on the same Twin HDMI Input Card, the Input1 signal is looped to Output1 and the Input2 signal is looped to Output2.
  • Page 89 Section 3: Operation • MANUAL ZOOM/FOCUS When this control is selected, the holding current is removed from the zoomand focus motors so that they can be changed manually. Zoom and Focus should not be adjusted manually when this control is not NOTE: selected, as this will result in damage to the motors.
  • Page 90 Section 3: Operation • TURN OFF IMAGE AFTER (min) This sets the activation interval (in minutes) for Auto Shutdown. If all activity (input signals, web or serial port activity, key presses) is lost for this length of time, and Auto Shutdown is enabled, an Auto Shutdown cycle will begin.
  • Page 91 • Start-up And No Signal – A splash screen appears at start-up and at any time when there is no signal. To add your own splash screen in addition to the default “Christie logo” splash screen, use the Web UI to download the desired bitmap (.bmp) file to the projector.
  • Page 92 Section 3: Operation • PROJECTOR ADDRESS Enter a three-digit number (such as “001”) to assign or change a number to the projector currently in use. If the current projector already has a number assigned, that number will appear here (for example “004” in the menu shown below.
  • Page 93 Section 3: Operation ETHERNET SETTINGS - Submenu Recommended for network administrators only. NOTE: • IP CONFIGURATION Determines whether the IP Address is configured Static (manual) or Dynamic (HDCP). Dynamic (HDCP) is the factory default setting. • IP ADDRESS Enter a valid and unique IP address for use on the network to which the projector is currently connected. This address will overwrite any previous IP address such as the projector factory-defined default.
  • Page 94 Section 3: Operation • If both interfaces are selected, the DMXC input card will take priority if it is actively receiving data. While data is active on this card, ArtNet packets will be ignored. • Only 1 DMXC card can be used at a time. If more than one is populated, the 2nd and subsequent cards will not be activated.
  • Page 95 DMX input. • HOST NAME This will be used to respond to ArtNet polling queries. "Christie" will be the short name, "Christie_HostName" will be our long name. By default the host name is composed from the projector name and serial number.
  • Page 96 Section 3: Operation Horizontal keystone is used to correct a keystoned image shape in which the left and right borders of the image are unequal in length, and the top and bottom are slanted to one of the sides, see Figure 3-34 Horizontal Keystone.
  • Page 97 Section 3: Operation The F key combination will immediately disable the Keystone, Brightness Uniformity, Edge Blending and Black Level Blending features. This is helpful when, in some extreme keystone configurations, some image corruption may appear and/or the menus may not be readable. Although F disables these features, it will not overwrite their settings.
  • Page 98 Section 3: Operation  Always adjust brightness uniformity for a User color temperature USE A “USER” COLOR TEMPERATURE— defined when you matched primary colors, and continue to use it for all sources displayed on the wall. Your other color temperatures will not necessarily be matched from screen-to-screen. ...
  • Page 99 Section 3: Operation b. Return to the Brightness Uniformity menu. Beginning with the screen that exhibits the most obvious color shift(s), for each edge that exhibits a noticeably different color temperature from the center, select the corresponding Uniformity adjustment menu—Left, Right, Top or Bottom. For example, if any part of the left side is too blue, too red or too green, go to the Left Uniformity menu and adjust the colors (i.e., change their light output) until all portions of the left side closely match the center color temperature.
  • Page 100 Section 3: Operation What is a Blend? In simple terms, a blend appears as a gradient strip along an edge of a projected image. It is darkest along the extreme edge of the image, and lightens nearer to the rest of the image (see right). How Are Blends Used? In multiple-projector walls, complementary blends between neighboring images can compensate for the extra “brightness”...
  • Page 101 • Show Blending Overlap turns your defined blend width area to solid grey so that, if needed, simply overlapping the grey bars can seamlessly align two adjacent images. Toggle the Show Blending Overlap off to reactivate the blend effect. Blending Overlap appears as Reserved when Christie TWIST is NOTE: installed.
  • Page 102 Section 3: Operation COLOR ADJUSTMENTS BY X/Y - Submenu Enter known x/y coordinates from the chromaticity graph For defining or changing a User 1, 2, 3, or 4 color NOTES: 1) performance or “gamut”. Sometimes known as Comprehen- sive Color Adjustment™. Factory-defined primary color levels, which ensure a specific color performance from projector-to-projector, can be calibrated in the Service menu...
  • Page 103 Section 3: Operation 3-38 CIE 1931 C IGURE HROMATICITY IAGRAM Keep new x,y coordinates within the original color gamut triangle shown here. NOTE: COLOR SATURATION - Submenu Adjust color slide bars and judge image color by eye or meter. A user-defined color “adjustment” can be applied by selecting it in the Advanced Image Settings menu (select ‘Color Adjustment’).
  • Page 104 Section 3: Operation Procedure Adjust white levels before adjusting black levels. The zones in BLB menu correspond to the Edge NOTES: 1) Blend zones. If a given Edge Blend zone width is set to 0 (i.e. no blend on that side) then the corresponding BLB zone is disabled.
  • Page 105 HDCP repeater negotiations with the source player. When the FUNC+HELP key combination is pressed, the tiling settings will be cleared. HINT: Tiled warps/keystones can be enabled through Christie TWIST 1.6; Refer to the Christie TWIST User NOTE: Manual.
  • Page 106 3.8.10 SERVICE- Submenu Access restricted to Christie accredited service technicians. 3.8.11 OPTION CARD SETTINGS - Submenu Allows adjustment of any settings specific to each option card that is currently installed in the projector. Refer...

  • Page 107: Lamp Menu

    Section 3: Operation Lamp Menu LAMP MODE Determines how the lamp power and intensity are controlled. If Maximum Brightness is selected, the lamp burns as brightly as possible. Select Constant Intensity mode to maintain a specific brightness level over time. As the lamp ages, the projector will increase power as needed, to closely maintain the required output from the lamp.

  • Page 108: Main Input

    Section 3: Operation CHANGE LAMP - Submenu Initiates the lamp change process and allows the serial number of the new lamp to be entered. Lamp serial numbers are used for keeping statistics on each lamp. Entering of serial numbers is optional, but is recommended.
  • Page 109 Section 3: Operation PIP WINDOWS OPTIONS - Submenu • PIP POSITION PRESETS Select a preset location and size of the PIP window. While in split screen mode, several channel controls that resize image will be disabled. These controls are size, H-Position and V-Position. •...

  • Page 110: Status

    Section 3: Operation HDMI OUTPUT LOOP SOURCE Configure the HDMI output options. Select Direct Loop to directly pass-through the HDMI input signals (from the same Twin HDMI Input Card). The Input1 signal is looped to Output1 and the Input2 is looped to Output2. Select Main/Secondary Loop to loop the Main &...
  • Page 111 Section 3: Operation Preliminary Calibration All primary colors in the projector are precisely set to pre-established values to ensure that overall color performance is optimized and is as accurate as possible. Lighting and other environmental factors may slightly change how these colors appear on your screen. While the change is negligible in most cases, you may prefer to recover the originally intended color performance before trying to match colors from several projectors.
  • Page 112 Section 3: Operation • Display the Color Adjustments by X,Y menus for all projectors. Each menu shows the x/y coordinates defining the “Max Drives” color gamut for this projector. The values shown in one (any) of the NOTE: displays. Use the “Copy From” function to copy them into a “User” gamut in one projector. 3-40 J X/Y V IGURE...
  • Page 113 Section 3: Operation • To match reds, decrease “Red X” until full field red screens match. • To match greens, decrease “Green Y” until full field green screens match. • To match blues, increase both “Blue X” and “Blue Y” until full field blue screens match. For speed, enable the “Auto Color NOTE: Enable”...

  • Page 114: Remote Control Of The Projector

    VIA ASCII MESSAGING — Connect a serial link between your controller and the RS-232 or RS-422 port (recommended), or open an Ethernet socket (i.e., Telnet) between your controller and the valid projector address. Valid ASCII codes and messages are documented in the Christie Serial Communications document available at the Christie website.

  • Page 115: 4: Web User Interface

    4 Web User Interface Logging On Before logging on to the system, ensure that you select the appropriate language IMPORTANT! required. Your language selection only affects the web user interface. The language used by the projector on-screen display (OSD) is not affected. See Figure 4-1.

  • Page 116: Navigating The Web User Interface

    Section 4: Web User Interface The following table describes each area found in the Main window. See Figure 4-3. ECONDARY SPECIFIC TO CTIVE NPUT INDOW SEC- HESE SECTIONS PROVIDE DROP A PRIMARY TAB LOCATED TION IS READ ONLY DOWN LIST SELECTIONS REFER 3, O ALONG THE BOTTOM OF THE...

  • Page 117: Basic Operation

    Section 4: Web User Interface Basic Operation This section discusses the primary tabs located along the top of the application window. Each primary tab also has related secondary tabs which are located along the bottom of each tabbed page as follows: •...

  • Page 118: Main Tabbed Page - Lens

    Section 4: Web User Interface 4.3.3 Main Tabbed Page - Lens Under the Main tabbed page, select the Lens secondary tab to define your adjustment settings for the lens. For detailed information, refer to Section 3 Operation. 4.3.4 Tools Tabbed Page - Virtual OSD Under the Tools tabbed page, select the Virtual OSD secondary tab to access to the virtual OSD page.
  • Page 119 Section 4: Web User Interface Virtual OSD Menu By selecting an option from a menu, its associated window appears, showing related information and input fields. To return to the previous menu, click the menu title bar (see Figure 4-7). To return to a previous menu, click on the current menu title bar or press ESC.

  • Page 120: Admin Tabbed Page - System

    Section 4: Web User Interface ELECTING A OPTION FROM A DROP DOWN LIST 1. Click the option drop-down arrow to open the drop-down list. 2. Locate and select the desired option. 4-9 T IGURE YPES OF LEMENTS ELECTING OR CLEARING A CHECK BOX To select or clear a check box, click the check box with your mouse pointer.
  • Page 121 Section 4: Web User Interface The following table describes each area found in the Admin window. See Figure 4-10. ESTORE SECTION ALLOWS ACKUP SECTION ALLOWS PLOAD SECTION ALLOWS YOU TO SELECT THE FILE YOU TO SELECT THE FILE AND YOU TO SELECT THE FILE AND AND FILE TYPE THAT YOU FILE TYPE THAT YOU WISH TO FILE TYPE THAT YOU WISH TO...

  • Page 122: Admin Tabbed Page- Users

    Section 4: Web User Interface 4. Click the Upload button to display the Logo Upload window. a. Enter a descriptive name in the Display Name field. b. Click the Upload button to display the Gamma Upload window. Click Yes or No to confirm or cancel the upload respectively.

  • Page 123: Advanced Tabbed Page - Rte

    Section 4: Web User Interface Creating a User Name and Password 1. Click Add User to open the Add User window. See Figure 4-11. 2. Type your username and password in the User name and Password fields respectively. 3. Re-type your password in the Re-type Password field. 4-11 A IGURE SER WINDOW...
  • Page 124 Section 4: Web User Interface DD A CHEDULED VENT 1. Click Add to open the RTE Wizard. 2. Select the Scheduled Event tab. The scheduled tab is always selected by default on add. NOTE: 4-14 S IGURE CHEDULED VENT INDOW 3.
  • Page 125 Section 4: Web User Interface • Click the Test button to test the entered command string. If the test passed or failed, a green or NOTE: red icon appears to the right side of the Test button as shown in Figure 4-16 Test Buttons.
  • Page 126 Section 4: Web User Interface To Add a GPIO Event 1. Click Add to open the RTE Wizard. 2. Select the GPIO Event tab. 3. For the GPIO Event option define the Input Condition field as required. The Input Condition field contains 7 blocks which refer to the 7 I/O pins on the GPIO connector.

  • Page 127: About Tabbed Page

    For Serial Commands refer to the M NOTE: Series Serial Commands Technical Reference Information P/N 020-100224-xx, available at the Christie Website. 2. Click Send to add the serial command. See Figure 4-22. 4.3.8 About Tabbed Page Provides information about the projector software version, model, serial number, and license information.

  • Page 129: Projector Location

    “hotspot,” which could potentially result in lamp failure. It is recommended you wear a face shield when working with the lamp. For this procedure you will need the appropriate Lamp and Filter Kit manufactured by Christie Digital Systems. See Table 5.1.
  • Page 130 Section 5: Maintenance Table 5.1 Projector Part Number Projector Model Lamp Type Lamp/Filter Kit Required Roadster S+14K-J 132-010113-xx 2.0 kW 003-120135-xx Mirage S+14K-J 132-010124-xx Roadster HD14K-J 132-011114-xx Mirage HD14K-J 132-011125-xx Mirage WU14K-J 132-012126-xx Matrix WU14K-J 132-012137-xx Roadster S+18K-J 132-013116-xx 2.4 kW...
  • Page 131 Section 5: Maintenance 3. REMOVE THE LAMP MODULE Protective gear required. Wear a face shield. Using a #2 Phillips screwdriver, loosen the two (2) lock screws securing the lamp door, which is located at the rear of the projector below the Input panel. See Figure 5-1.
  • Page 132 Section 5: Maintenance 5. REMOVE THE LAMP MODULE Make sure the lamp insertion/removal handle hook is located behind the lamp module (Figure 5-3) and pull lamp module off of electrical terminal by pulling on the insertion/removal handle. Carefully pull on the lamp module handle to remove the lamp.
  • Page 133 If this filter is not replaced, airflow may become restricted and cause the projector to overheat.Use the filter provided in the Christie approved Lamp and Filter Kit for your specific projector model. See Table 5.1. 1. TURN OFF THE PROJECTOR, COOL AND UNPLUG Before removing or installing a filter, turn off the projector and allow it to cool for 5 minutes before unplugging.

  • Page 134: Replacing The Projection Lens

    Section 5: Maintenance 3. REPLACE FILTER Remove the old filter and insert the new one. The direction arrows on the outside edge of the filter. NOTE: Ensure the filter is installed with the arrows pointing into the projector. 4. RE-INSTALL THE FILTER DOOR Secure the lock screw.
  • Page 135 Section 5: Maintenance 3. While holding the lens flat against the lens mount, rotate the lens clamp clockwise to lock the lens assembly in place. See Figure 5-9 . IGURE 4. Remove the front lens cap. 5. For added stability such as motion applications, fasten the security screws provided with the lens mount. Figure 5-10.

  • Page 136: Cleaning The Lens

    Section 5: Maintenance Cleaning the Lens Check periodically. A small amount of dust or dirt on the lens has minimal effect on image quality. To avoid the risk of scratching the lens, clean only if absolutely necessary. Dust: 1. Brush most of the dust from the lens with a camel-hair brush and/or blow dust away with a dust-free blower.
  • Page 137 Section 5: Maintenance Refilling Liquid Coolant Module 1. Using a flat head screwdriver, remove the fill port cap and the air vent cap. See Figure 5-11. 2. Using a funnel and coolant, fill the liquid cooling module until the coolant is within 2mm of the top cover. 3.

  • Page 138: Power Cord And Attachments

    Refer to Section tions • Only use attachments or accessories recommended by Christie, such as the specific power cord supplied. Use of other attachments or accessories with this projector may result in the risk of fire, shock or personal injury.

  • Page 139: Ventilation

    Servicing Requirements If any of the following conditions exist, immediately unplug the projector from the power outlet and refer service to Christie accredited service personnel. • The power cord has been damaged • The internal cooling fans do not come on within two minutes after the projector is first turned on •...

  • Page 141: Power

    If the projector is not operating properly, note the symptoms and use this section as a guide to resolve the problem. If the problem cannot be resolved, contact your dealer for assistance. : A Christie accredited NOTE service technician is required when opening an enclosure to diagnose any “probable cause”.

  • Page 142: Lamp Suddenly Turns Off

    Section 6: Troubleshooting 6.2.2 Lamp Suddenly Turns OFF 1. Check lamp power through the remote keypad checking the Lamp menu or from the web user interface Advanced: Lamp menu. Try increasing lamp power. 2. Check for an alarm condition on the LCD keypad display. 3.

  • Page 143: Osd

    Section 6: Troubleshooting 6.5.1 The OSD Menu does not display 1. Using the LCD, ensure that OSD menu is enabled, scroll-down until the item OSD appears. The LCD shows “OSD: off”. Press and hold the OSD soft key on the built-in keypad. The LCD now shows “OSD on”...

  • Page 144: Image Appears 'Squeezed' Or Vertically Stretched Into Center Of Screen

    Section 6: Troubleshooting 6.7.3 Image Appears ‘Squeezed’ or Vertically Stretched into Center of Screen 1. Run auto setup, pressing Auto button on the remote keypad. 2. Check your Resizing selection. 6.7.4 The Display is Jittery or Unstable 1. If the display is jittery or blinking erratically, ensure that the source is properly connected and of adequate quality for detection.

  • Page 145: Display Has Suddenly Frozen

    Section 6: Troubleshooting 6.7.11 Display has Suddenly Frozen If the screen blacks out inexplicably, it is possible that excessive voltage noise on the AC or ground input has interrupted the projector ability to lock on to a signal. Power down the projector and disconnect from AC. Then plug in again and power up as usual.

  • Page 146: Web Interface

    Section 6: Troubleshooting Web Interface 6.8.1 After upgrading the projector software, the Web pages do not display correctly 1. After upgrading, the temporary internet files and cookies must be cleared from the Web Internet Browser to ensure that Web UI changes can take effect. 2.
  • Page 147 Section 6: Troubleshooting IGURE J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev. 1 (10-2011)

  • Page 149: Image Performance

    7 Specifications This section provides detailed J Series features; including inputs, lamp, and power requirements. NOTE: Due to continuing research, detailed features are subject to change without notice. Image Performance 7.1.1 Pixel Format 1080p (H x V square pixels) 1920 x 1080 SXGA+ (H x V square pixels) 1400 x 1050 WUXGA (H xV square pixels)

  • Page 150: Grayscale/Color Resolution

    Section 7: Specifications 7.1.6 Grayscale/Color Resolution Resolution 10 bits (non-linear) min. (Gamma encoded) 7.1.7 Color Temperature White Default CCT 7250K ±950K Range of Adjustment 3200 K - 9300 K Tracking (deviation from normal over full ±500 K max range from 10 – 100 IRE) Stability (during rated lamp life) ±500 K max 7.1.8 Convergence...

  • Page 151: Blemishes

    Section 7: Specifications 7.1.9 Blemishes Red screen No blemishes Green screen No blemishes Blue screen No blemishes White screen No blemishes Black screen No blemishes 7.1.10 Pixel Defects 0 bright, up to 1 dark Green 0 bright, 0 dark Blue 0 bright, up to 2 dark non-adjacent Feature Set 7.2.1 Airflow...

  • Page 152: Projection Lens Compatibility

    Section 7: Specifications 7.2.5 Projection Lens Compatibility Lens type Reverse Telecentric Internal-focus Motorized zoom and focus with position feedback NOTE: Calculated Throw distance values are subject to a ±5% lens tolerance Lens Throw Ratio Throw Ratio Lens Description Part Number SXGA+ WUXGA Lens ILS 0.73:1SX+/0.67:1HD...

  • Page 153: Shutter

    Section 7: Specifications 7.2.8 Shutter Open Light transmitted to projection lens Closed All light blocked - no light on screen 7.2.9 Lamps Ushio Xenon bubble lamp system Lamps are accessed from the rear of the projector 7.2.10 Status LED Status LEDs LED STATES Lamp Off –...

  • Page 154: Image Processor Performance

    Section 7: Specifications Image Processor Performance Min input pixel rate 13 Mpix/s Max input pixel rate 165 Mpix/s Standard Mode Standard Image Processor 330 Mpix/s High Bandwidth mode Dual Image Processor Max input resolution 2048x1536 (QXGA) Min input resolution 640x400 Max input frame rate with Dual 120Hz at 2048x1080 Dual Image Processor (DIPC) required...

  • Page 155: Dual Link Dvi Input

    Section 7: Specifications 7.4.3 Dual Link DVI Input Connectors 1 dual link DVI-I 1 analog 15-pin VGA Color spaces/signal types HDCP support A/D conversion 10 bits for single link DVI input 8 bits for dual link DVI inputs Frequency 165 MPixel/s analog 330 Mpix/s Dual link DVI (requires DIPC) 7.4.4 Video Decoder Input Connectors...

  • Page 156: Ethernet

    Section 7: Specifications 7.5.3 RS-232 Number of ports Connector 1 female 9-pin Dsub (IN) 1 male 9-pin Dsub (OUT) Max bit rate 115.2 kbps Flow control Xon/Xoff 7.5.4 RS-422 Number of ports Connector 1 female 9-pin Dsub Max bit rate 115.2 kbps Power output 12 V ±5% @ 400mA maximum...

  • Page 157: Power Requirements

    Section 7: Specifications Power Requirements Parameter Lamp Power Requirement Rated Voltage 3000W 200 VAC - 240 VAC 2400W 200 VAC - 240 VAC 1900W 200 VAC - 240 VAC Rated Current 3000W 20 A 2400W 16 A 1900W 14 A Line Frequency 50/60 Hz AC Input Coupler...

  • Page 158: Adjustment

    Section 7: Specifications 7.7.2 Adjustment Product Alignment 50mm (2”) of vertical adjustment on 2 front feet and 2 rear feet. 7.7.3 Weight Maximum product weight (with lens removed) 72.5kg (160lb.) Maximum shipping weight (includes packaging) 91kg (200lb.) Reliability and Serviceability 7.8.1 Reliability MTBF –...

  • Page 159: Accessories And Service Components

    Section 7: Specifications 7.10 Accessories and Service Components Product Name Part Number Sold With Sold Product Separately Analog Input 108-309101-XX Dual Link DVI Input 108-312101-XX Video Decoder Input 108-310101-XX Dual 3G/HD/SD-SDI Input Card 108-313101-XX Twin HDMI Input 108-311101-XX DMX512 Interface 108-314101-XX Dust Filter Fog Filter...
  • Page 160 Section 7: Specifications 7.11.2 Electro-Magnetic Compatibility Emissions • FCC CFR47, Part 15, Subpart B, Class A - Unintentional Radiators • CISPR 22: 2008-09/EN55022: 2006 + A1:2007 Class A - Information Technology Equipment Immunity • CISPR 24: 1997 +A1:2001+A2:2002/ EN55024: 1998 +A1:2001 +A2:2003 EMC Requirements - Infor- mation Technology Equipment 7.11.3 Environmental The product must conform to:...

  • Page 161: J Series Menu Tree

    Appendix A: Menu Tree A.1 J Series Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev. 1 (10-2011)
  • Page 162 Appendix A: Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev. 1 (10-2011)
  • Page 163 Appendix A: Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev.1 (10-2011)
  • Page 164 Appendix A: Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev.1 (10-2011)
  • Page 165 Appendix A: Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev.1 (10-2011)
  • Page 166 Appendix A: Menu Tree J Series 2.0, 2.4, and 3.0kW User Manual 020-100707-01 Rev.1 (10-2011)

  • Page 167: Gpio Port

    Appendix B: GPIO This section explains how to use a GPIO link from the projector to external equipment, such as devices for 3D synchronizing. B.1 GPIO Port The GPIO connector located on the input panel provides a flexible method of interfacing a wide range of external I/O devices to the projector.
  • Page 168 Appendix B: GPIO Configuring the GPIO The GPIO connector can be configured to automate any number of events using the serial command code GIO. Each Pin is defined as either an input or output depending on the desired outcome. Configure the pin as an input if you want the projector to respond to something the device does and as an output if you want the external device to respond to an action taken by the projector.

  • Page 169: Dmx And Real Time Events

    Appendix C: DMX / ArtNet C.1 DMX and Real Time Events What is DMX? DMX is a standard for digital communication networks that are commonly used to control stage lighting and effects. What is Real Time Events? A real time event is a pre-recorded sequence of 1 or more serial commands which are executed when a defined trigger occurs.

  • Page 170: Dmx Channel Setup

    Appendix C: DMX / ArtNet C.1.1 DMX Channel Setup Each personality has a different number of channels: • Setup Personality - 38 channels • Show Personality - 18 channels • ZAP VIP Projector Yoke Personality - 25 channels It is very important to properly configure the base channel (depending on which personality is used) correctly. While the DMX specification allows for device overlapping, this may cause undesired results.
  • Page 171 Appendix C: DMX / ArtNet J Series Setup Personality Default Channel Group Name Description Notes Value No Channel changes will be applied when this control is locked. Channel changes 0-171 Locked Safety Slider Lock made while the slider is 172-255 Unlocked locked will be applied once the slider becomes unlocked.
  • Page 172 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value Input Selection 0 to 9 Slot 1, Input 1 10 to 19 Slot 1, Input 2 ..50 to 59 Slot 1, Input 6 60 to 69 Slot 2, Input 1 ..
  • Page 173 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value 0-19 Off 20-39 Grid 40-59 Grey Scale 16 60-79 White 80-99 Flat Grey Setup Func- 100-119 Black Test Pattern tions 120-139 Checker 140-159 13 Point 160-179 Color Bars 180-199 Aspect Ratio 200-219 Edge Blend 220-239 Boresight...
  • Page 174 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value Real Time RTE 1 0-85 Cancel current running RTE Events 172-255 Triggers RTE 1 Real Time 0-85 Cancel current running RTE RTE 2 Events 172-255 Triggers RTE 2 Real Time RTE 3 0-85 Cancel current running RTE...
  • Page 175 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value Lens Vertical Lens position (Coarse) 0 to 255 Scaled as % of total control Locked by channel “lens range, which is 0 to 4096 shift enable”. Lens Vertical Lens position (Fine) Projector Channel Selection...
  • Page 176 Appendix C: DMX / ArtNet J Series ZAP VIP Projector Yoke Personality Default Channel Group Name Description Notes Value If a value of 0 is set, the shutter will be closed. Any 0-85 Black screen (Picture mute ON) non-zero values will open 172-255 Live video (Picture mute OFF) Fade to/from the shutter.
  • Page 177 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value Projector Orientation 0-9 Front Projection 10-19 Rear Projection 20-29 Front Projection Inverted 30-39 Rear Projection Inverted On Screen Display 40-59 OSD On 50-59 OSD Off 60-69 Lens Calibrate 86 LOAD Test Pattern 100-104 Off...
  • Page 178 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value Color Space 0-9 RGB 10-19 YCbCr SDTV (ITU-R BT.601) 20-29 YCbCr HDTV (ITU-R BT.709) 86 LOAD Output Color 90-99 Max Drives Video Signal/ 100-109 Color Temperature (enables 21) Colorimetry Color space, 110-119 SD Video...
  • Page 179 Appendix C: DMX / ArtNet Default Channel Group Name Description Notes Value 0-9 Cancel current running RTE 10-19 Triggers RTE 1 20-29 Triggers RTE 2 30-39 Triggers RTE 3 40-49 Triggers RTE 4 Real Time 50-59 Triggers RTE 5 Events 60-69 Triggers RTE 6 70-79 Triggers RTE 7 86 LOAD...
  • Page 181 *000-102356-01* ASSY TECH DOCS J Series 2.0, 2.4, and 3.0kW...
  • Page 182 Corporate offi ces Worldwide offi ces USA – Cypress United Kingdom Eastern Europe Singapore Japan ph: 714-236-8610 ph: +44 118 977 8000 ph: +36 (0) 1 47 48 100 ph: +65 6877-8737 ph: 81-3-3599-7481 Canada – Kitchener France Middle East Beijing South Korea ph: 519-744-8005...

This manual is also suitable for:

Roadster hd14k-jRoadster s+18k-jRoadster s+22k-jRoadster hd20k-jRoadster wu20k-jRoadster hd16k-j

Table of Contents
