14. DVR WINDOW

Any DVR that has been added into the CMS using the DVR Set List Manager will be listed under the DVR
window with its own DVR icon and name. Moreover, individual DVR icons also act as a supplementary
icon to display individual DVR's status.
The status of the DVR is displayed in five different icons.
1) Normal
2) Network connection in progress
3) Network Error / Disconnection
4) System abnormality
of the DVR since its first connection to the CMS.
When the DVR is working within normal parameters, the icon color remains blue.
Double-click on the icon to begin live monitoring.
When the CMS program is first run or when the DVR has been added for the first
time, the icon will display an exclamation point and will change its color to orange.
If the DVR is disconnected due to a network error, or if the CMS was not able to
connect to the DVR due to an invalid address, port or password, the icon will
display a "prohibited" sign and will change its color to pink.
If alarm, motion trigger or some system abnormalities such as video loss occurs,
the icon will display a question mark and change its color to orange.
Double-clicking on the icon will open the CMS log list, displaying all the past events
If the icon is double-clicked while the
connection is in progress, "Connecting...
please stand by." pop-up window will
appear. Click on Retry to reinitiate the
connection process or Cancel to return to
the main window.
If the icon is double-clicked while the DVR
is disconnected or if the password has been
changed on the DVR, "Network connection
error." pop-up window will appear. Click on
Retry to reinitialize the connection process
or Cancel to return to the main window.
90
DV TURBO SERIES DVR
