Block Color
Solid Red
Blinking Red
Solid Yellow
①
NUMBER
The order the DVR was entered. In case of network connection error or power failure, this block will blink
in red in conjunction with the NAME block.
②
NAME
DVR name, either the host name or something created by the user. In case of network connection error
or power failure, this block will blink in red in conjunction with the NUMBER block.
③
HDD FAIL
Notifies Hard Drive Disk failure during the operation.
④
SYSTEM FAN LOCK
Notifies System Fan abnormality.
⑤
CPU FAN LOCK
Notifies CPU Fan abnormality.
⑥
ALARM TRIGGER
Notifies the alarm trigger.
⑦
MOTION TRIGGER
Notifies motion detection.
⑧
VIDEO LOSS
Notifies loss of video signals.
⑨
SYSTEM OVERALL TEMPERATURE
Notifies if the temperature in the DVR rises above abnormal level.
⑩
CPU OVERALL TEMPERATURE
Notifies if the CPU temperature rises above abnormal level.
⑪
REC LED INDICATOR
Displays the status of the recording LED from the DVR. Switches to yellow if inoperative.
⑫
SCHEDULE LED INDICATOR
Displays the status of the schedule LED from the DVR. Switches to yellow if inoperative.
⑬
BACKUP
Displays the status of the schedule LED from the DVR. Switches to yellow if inoperative.
Any DVR name or number, or any of the lit or unlit blocks may be double-clicked to access the properties,
CMS log list and DVR log list. Please refer to pages for more information.
Definition
An event or a problem had occurred
Current event or a problem
Current status of the DVR
