1.1.3 Border Line

1.1.4 Background

1.1.5 Display Device

1.1.6 Split Mode

Select the border line color from the following available
colors:
•
Black
•
Dark Gray
•
Gray
•
White
The default border line color is White.
Select the background color from the following available
colors:
•
Black
•
Dark Gray
•
Gray
•
Blue
•
White
The default background color is Gray.
Select the main video output.
•
CCTV Monitor: composite video signal output using
BNC connectors and VGA output.
•
PC Monitor: VGA output only.
1. Pressing Hold and Key Number 3 for 3 seconds will
force the unit to use CCTV Monitor
2. Pressing Hold and Key Number 4 for 3 seconds will
force the unit to use PC Monitor.
Select to display different types of split screen modes.
You can select between 4ch, 6ch, 7ch, 8ch, 9ch, 10ch, two
types of 13ch, and 16ch.
The default split has been selected to 4ch, 9ch and 16ch.
