3.2 Iris Control

Button
3.3 Preset & Tour
Button
a. Move the PTZ into desired location.
b. Press the Preset button.
c. User 1 will illuminate.
d. Set the # for the Preset location.
e.
a. Press Go to button.
b.
a. Press Auto Tour Button.
b. Press the + button and enter the range of Preset and press Enter.
c.

3.4 Custom Functions

Button

3.5 Auto Pan / Auto Tilt / Power

Button

3.6 Boundaries

Button
Iris Open; TIME SEARCH on remote controller
Iris Close; EXT. SEARCH on remote controller
Auto Iris; LOG on remote controller
Set preset position; SPOT OUT on remote controller
Press Enter to save and exit.
Go to preset position; INFO on remote controller
Enter the desired Preset # and press Enter.
Start Auto Tour; BACKUP on remote controller
For Example, Auto Tour Button, +5 will start the tour of 1 ~ 5 presets of the
PTZ Camera
PTZ custom function 1; DISPLAY on remote controller
PTZ custom function 2; ZOOM on remote controller
PTZ custom function 3; P/T/Z on remote controller
Auto Pan; STOP on remote controller
Auto Tilt; REW on remote controller
Power on / off; FF on remote controller
Function
Function
Function
Function
Function
42
