LCD
Settings Explanation
display
O/P V
Output Volt.Setting Select Nominal Voltage
Setting
Select input frequency
Input/Frequency I/P F Setting range when UPS goes into
free run mode
Input/Bypass I/P Bypass Select Input Voltage range
Voltage Set when bypass is available
Select if UPS can run in
Free Run
Free Run Mode Free run mode
Set
(unsynchronized)
Bypass If Enable is chosen, the
Bypass
Enable/Disable at UPS can go to bypass when
disable
Free run mode unsynchronized.
HE Mode Select if UPS runs in high
He mode Setting
Set efficiency mode
Force Manual Manual Permanently force UPS to
Bypass bypass bypass. For service only.**
Detect battery is normal or
Do Battery Test Battery Test
not.
Enable or disable silence
Silence Function Silence Set
function
Number of This setting is needed
Bat Cabinet
External battery For UPS to predict
Set
Packs Backup time
You can enable or disable
Site wiring alarm Sit Fault Set
the site wiring alarm
Select Language Language Select load language
Set unit in generator mode.
Set Generator Mode Generator
***
Set RS232 RS232 Set RS232 communication
communication Control enable or disable
Manual test of the UPS
Manual UPS or Manual Battery tests can be conducted from the UPS configuration as well
and are functional even when the UPS is not charging the battery.
Manual Battery test: Scroll the parameters until Manual Bat test displays on the LCD.
Press the "ENTER" button twice.
Factory
Selection
default
208/220/230/240 V 230V
±2%
±5% ±5%
±7%
±10%
+10/-15% +10/-15%
+15/-20%
ON/OFF ON
Disable/Enable Disable
ON/OFF OFF
ON/OFF OFF
ON/OFF OFF
0 (only internal batteries)
1(one external cabinet) 0
2 (two external cabinets)
Enable /Disable Disable
English, German, French,
English
Spanish, Italian.
ON/OFF OFF
Enable/Disable Enable
20
**) Note: In order for the UPS and power management software to operate normally,
Manual Bypass should always be set to OFF as the load will not be protected by the unit
when Manual Bypass is ON. This is aimed for operating an external maintenance bypass
switch.
***) Note: You should turn UPS off and keep the AC power before you use "Generator"
function. (even you want to select "\Generator\OFF" to back to normal mode).
