5K VA – 12K VA UPS
■User's and Installation Manual■
EMC Statements
CISPR 22
NOTICE: Pursuant to CISPR 22 rules, this product has been tested and thereby complies to
the conditions of a Class A digital device, which have been established for offering
sufficient protection against dangerous interference for installation in a residential area.
Installation and use of the equipment should comply with the instructions provided in order
to avoid such interference due to the amount of radio frequency energy that is radiated and
generated by the equipment. In spite of this, we cannot assure that a certain amount of
interference may not occur in some installations. If, by turning on and off, it can be deduced
that your radio or television reception is found to be influenced by harmful interference
from the equipment, it is recommended to use one of the following preventive measures:
Place the receiving antenna in a separate location or orientation.
Ensure a greater distance is achieved between the receiver and the equipment.
Ensure that your equipment is connected to an outlet on a separate circuit than the
receiver.
Contact a technician experienced with radio and TV or a dealer for further assistance.
Declaration of Conformity Request
Units labeled with a CE mark comply with the following standards and directives:
Harmonic Standards: EN 50091-1-1 and EN 50091-2
EU Directives:73/23/EEC, Council Directive on equipment designed for use within
certain voltage limits
93/68/EEC, Amending Directive 73/23/EEC
89/336/EEC, Council Directive relating to electromagnetic compatibility
92/31/EEC, Amending Directive 89/336/EEC relating to EMC
The EC Declaration of Conformity is available upon request for products with a CE
mark.
I
Advertisement
Table of Contents
Related Manuals for Powercom 5K VA
Summary of Contents for Powercom 5K VA
-
Page 1: Emc Statements
In spite of this, we cannot assure that a certain amount of 5K VA – 12K VA UPS interference may not occur in some installations. If, by turning on and off, it can be deduced... -
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS 1. Introduction ...................1 SAVE THESE INSTRUCTION 2. System description................1 2.1 General description..................1 CAUTION (UPS Having Internal Batteries): Risk of electric shock ● 2.2 System configuration ...................3 - Hazardous live parts inside this unit are energized from the battery supply even when the input AC power is disconnected. -
Page 3: Introduction
The instructions contained within this safety manual are deemed important and 1. Introduction should be closely followed at all times during installation and follow-up maintenance of the UPS and batteries. The information provided in this manual covers single phase 5000 – 12000 VA, uninterruptible power systems, their basic functions, operating procedures, and emergency situations, also including information on how to ship, store, handle and install the CAUTION... -
Page 4: System Configuration
2.2 System configuration The UPS device and the internal backup battery make up the system. Depending on the site Inverter By-pass PFC&Booster Filter Filter and load requirements of the installation, certain additional options are available as a switch tailored solution. Planning a UPS system, the following should be taken into consideration: Charger &... -
Page 5: Safety Information
3. Safety information 4. Storage Information presented here is vital to all personnel and please also read the UPS safety 4.1 Storage manual. Please adhere to the following instructions if the UPS is not installed immediately: Storage and Transportation Store the equipment as is in its original packing and shipping carton Do not store in temperatures outside the range of +15°C to +25°C. -
Page 6: Installation
5. Installation 5.2 Rear panel views 5.1 Environment 5K~6KVA Ensure that all environmental concerns and requirements are met according to these Rear panel technical specifications, otherwise the safety of installation personnel cannot be guaranteed and the unit may malfunction. (Without ISO) Ensure that you remember the following when locating the UPS system and battery options: Avoid extremes of temperature and humidity. - Page 7 5K~6KVA 8K~12KVA Rear panel Rear panel (With ISO) (Without ISO)
-
Page 8: Connection To Mains And Loads (5000 - 12000 Va)
5.3 Connection to mains and loads (5000 - 12000 VA) Only qualified specialists or technicians who conform to applicable safety standards may 8K~12KVA carry out the installation of this equipment. The installation must further comply with all local legislation and regulations. Rear panel Follow all installation and safety instructions very carefully, otherwise those performing (With ISO) -
Page 9: Default Settings At The Factory
5.4 Default settings at the factory Bypass input Static L N PE On the LCD display you will find several of the UPS parameters to select. Default settings Bypass are as follows: Settings Selection Factory default L N PE Output Voltage Setting 208/220/230/240 Vac 230V (FOR HV series) Rectifier ±10%... -
Page 10: Computer And Alarm Connections
6. Computer and alarm connections USB port (option) At the back of the UPS is an interface allowing direct communication with your computer Connecting the UPS to your computer is accomplished through the USB port on the back of system, the location of which can be found in figure 4. There is a RS232 serial data your computer. -
Page 11: Button Operation
7.2 Button operation 7.3 Control panel functions Please note the five operating buttons on the front panel: Operation of the UPS is indicated on the monitor panel with five LED indicators and an LCD screen. This display is also capable of alerting the user with audible alarms. “ON/OFF”... - Page 12 UPS meters display UPS configurations Various measurements are available through the UPS meters display; pressing 1. Various settings that have been chosen are shown in the UPS setting display. the button will scroll through the following meters: 2. To enter configuration mode, press the “FUNC” button for one second. The first configuration parameter will be shown on the LCD display.
- Page 13 **) Note: In order for the UPS and power management software to operate normally, Manual Bypass should always be set to OFF as the load will not be protected by the unit Factory when Manual Bypass is ON. This is aimed for operating an external maintenance bypass Settings Explanation Selection...
-
Page 14: Interpreting Ups Messages
7.4 Interpreting UPS messages 7.5 Trouble shooting Displayed on LCD Audible Alarm Alarm Description What You Should Do Troubleshooting procedures described here give simple instructions in determining UPS Output Overload Two Beeps per The UPS is overloaded (in Shut off the least important malfunctions. -
Page 15: Maintenance
8. Maintenance 10. Technical Specifications GENERAL With a minimal amount of maintenance, you can expect the UPS to application, otherwise consider changing the batteries. have a long life free of trouble. The most critical issues for Rated power 5000VA, 6000 VA, 8000 VA, 10000 VA, 12000VA at p.f 0.7 the reliability of the UPS are environmental issues. - Page 16 HV Model Terminal Block 5/6K TB 5/6K-ISO TB OUTPUT POWER 5000 VA 6000 VA 8000VA 10000VA 12000VA Connection Input Hardwired Hardwired Hardwired Hardwired Hardwired Connection Output Hardwired Hardwired Hardwired Hardwired Hardwired Battery type Lead-acid Lead-acid Lead-acid Lead-acid Lead-acid 9 Ah/12V 5 Ah/12V Ah/12V Ah/12V...
- Page 17 MAINTENANCE SWITCH INV. MAIN. INV. Φ NORMAL MAIN. PASS...
