OFFICE UPS
MULTI-DEVICE PROTECTION UPS
500S/600S/750S
USER'S MANUAL
1.Safety instructions
Thank you for selecting this uninterrupted power source. It provides you with
better protection for connected equipment.
Please read this manual!
This manual provides safety, installation and operating instructions that will help
you derive the fullest performance and service life that the UPS has to offer.
Please save this manual!
It includes important instructions for the safe use of this UPS and for quick
solutions factory service should take as the UPS comes into question.
Please save or recycle the packaging materials!
The UPS's shipping materials were designed with great care to provide
protection from transportation related damage. These materials are invaluable
if you ever have to return the UPS for service. Damage created during delivery
is not covered under the warranty.
Advertisement
Table of Contents
Related Manuals for Powercom 500S
Summary of Contents for Powercom 500S
- Page 1 OFFICE UPS MULTI-DEVICE PROTECTION UPS 500S/600S/750S USER’S MANUAL 1.Safety instructions Thank you for selecting this uninterrupted power source. It provides you with better protection for connected equipment. Please read this manual! This manual provides safety, installation and operating instructions that will help you derive the fullest performance and service life that the UPS has to offer.
- Page 2 2.CAUTION! • Caution: Risk of electric shock hazardous live parts inside this unit are energized from the battery supply even when the input AC power is connected. • Warning: To reduce the risk of fire, replace only with the same type and rating of fuse.
-
Page 3: Installation
3.Installation 3.1Note: When delivered and stored, the battery in OFFICE UPS will more or less lose charge. Full recharge will be achieved after about 4 hours of normal operation. Do not expect full battery run time during this initial recharge period. 3.2Plug OFFICE UPS into an activating outlet. - Page 4 4.Description and Operation 4.1Battery Power Outlets The four Battery Power output outlets will provide protection if under status of surge or battery backup. Plug your computer, monitor, and other “datacritical” device into these outlets. There is still appropriate space for an adapter block in the outlet configuration.
- Page 5 4.6 BACK UP indicator (YELLOW LED ) The LED illuminated when the UPS is supplying battery power to the loads. Accompanying Audible Alarm As soon as the utility power fails, the OFFICE UPS will sound an audile alarm. When the battery runs low to about 2 minutes of duration, the alarm will emit continuous beeps.
-
Page 6: Wall Mounting
5.Wall Mounting 5.1 It is acceptable for vertical or horizontal positioning of OFFICE UPS to a wall surface. Use the template above to place the securing fasteners (not supplied). Note: Place the On/Off control to the right for horizontal positioning, to the top for vertical. -
Page 7: Software Options
6.5 Place the OFFICE UPS face down on soft material. Loose the screw holding the top of the unit to the bottom. After it is released, use both thumbs to push battery cover tabs in and away from unit. 6.6 Once removing battery cover, pull back the battery retaining clip, and then tip the battery up and out. - Page 8 8.Computer Interface Port The computer interface port has the following characteristics: D-SUB 9 Pin Female Connector Low Battery Contacts Normally Mains Failure Open Common UPS Shut Down or RS232 TD Pin3 Signal High Min. 1 Second RS232 RD Pin2 RS232RTS Pin 7 RS232DTR Pin4 No Connection Pin Number...
- Page 9 SPECIFCATION MODEL KOF-500S KOF-600S KOF-750S OUTPUT Capacity (on battery) 500VA 600VA 750VA (surge rotection) 500VA 400VA 250VA Voltage (on battery) Simulated sine wave at 100/115/220/240 ±5% Frequency (on battery) 50 or 60HZ±0.5% Transfer Time 2/4 milliseconds, including detection time ±15% at line input...
-
Page 10: Remote Port
4.10 Surge Protection Battery Power Output 4.11 4.12 4.13 4.14 AC INPUT REMOTE PORT TEL/FAX/MODEM SURGE PRTECTION PORT...
