ENIGMA II Programming Manual page 25

Note: If there is any problem during CPM firmware update (current blackout, cable
remove, other), repeat the upgrade steps from 3. point (start Enigma II Uploader). If
there is any problem during update steps, you can try the following:
After choosing COM port (6. point, 3. STEP) choose the Selected Speed (Without
•
checking) option, and set speed to 57600.
Turn off the power supply of ENIGMA II unit.
•
Turn on the AC supply of ENIGMA II unit, then immediately click to START button for
•
firmware upgrade start.
Event list and menu names in ENIGMA unit also can be updated. For this after starting
Enigma II Uploader program, please choose CPM Data function, then choose the latest
language file from distributor (for example: cpm250_EBA14.bin file) for upgrade
language.
Note: For individual text of events use EniTerm software / Codetable.et files.
When web browser is used for event list review, it is possible to put the company logo to
the web browser site. For this the logo should be uploaded with Enigma II Uploader
program after choosing CPM Data upload function.
Note: Recommended resolution for logo is 600 (wide) x Any (height), JPG format, size
cannot be bigger than 20 kbyte.
To upload newest web browser menu file you can also use Enigma II Uploader program
CPM Data function. After uploading the cpm.dat file what you wish to use, you can see
the new web browser display.
Note: Web browser menu of IP card can only be uploaded on the web browser site of IP
card. Upload is possible in Data Upload menu. If the web browser site cannot be
uploaded from any reason, you can use IP address then /mpfsupload command for data
upload (for example: 192.168.1.232/mpfsupload) of ip.bin file. Default password for web
file upload is: 1234.
