3.5 DISPLAY / CARDS – telephone line card programming
After DISPLAY button push (DISPLAY LED is steady) and choosing telephone line card
(CARDS 1 – 8) it is possible to enter the chosen telephone line card settings menu with
F2 (SETUP) button.
CONSOLE
HSK LENGTH
CALLER ID
+
F1
It is recommended to modify the following settings only (if it is necessary):
HSK LENGTH
•
Here you can change the Handshake and Kissoff length of line card.
CALLER ID
•
ENABLE – The telephone numbers of the call to the given line card appears on LCD
display of ENIGMA II unit (if telephone number sending is enabled at service provider
and 'Caller ID Message' is enabled in Enigma II unit).
DISABLE – Telephone numbers from the given line card are not shown on ENIGMA II.
Note: Function might be useful for debugging during communicator connecting to
monitoring station, as the phone number is displayed in case of bad communication
format too.
Note: Before changing HSK SEQUENCE / TIMING always consult with your distributor.
Note: After choosing the telephone line card (CARDS 1 – 8), with F3 (STATUS) button
you can check the firmware version of the line card (for example: LC-2.20.BA14).
CARD 1 OPTIONS
120
ENABLE
–
F2
15
VER: CPM2.60.BC06
PAGE CANCEL
F3 F4
