Note: After changing radio receiver card parameters please always restart the receiver
unit. For this exit the menu, then F3 (UTIL) / F3 (RESET) / F3 (RESET).
Note: If you want to use more complex radio system (repeaters, more radio receiver
units, two-way communication, etc.) please consult with your distributor.
Note: After choosing the radio receiver card (RADIO A – B), with F3 (STATUS) button
you can check the firmware version of the radio card (for example: RCM2.11.B223).

4. SYSTEM PROGRAMMING WITH PC SOFTWARE

To use the monitoring receiver with monitoring PC connect the COM A (USB A) port to
the serial port of the monitoring PC (USB connector). Driver installation is automatic
(from Windows 7). After this the appropriate monitoring software settings should be
done (it means usually the serial port settings).
The process is the following in AlarmSyS monitoring software:
Start Alarm Start software → Start Alarm Setup and log in (ID: 1, Password: 1) → Setup
menu → Hardware Setup → Digital Receiver #1.
In pop-up window basically only Receive and process incoming messages option
should be enabled, then set the proper COM port (checking in Windows OS: Control
Panel / Hardware / Device Manager), then apply changes. After this the COM ERROR
should be restored in monitoring receiver, and receiver events are displayed on
monitoring software screen.
Note: If you need direct connection of IP card to monitoring software (through USB
connector of the card) set Baud Rate value to 57600 in monitoring software settings.
17
