ENIGMA II Programming Manual page 11

NETMASK
•
The used subnet mask in local area network.
GATEWAY
•
This address is required if the device optionally wants to realize external communication
(for example for WAN Test). Most of the times the gateway address is the same as
rooter private (internal) address in local area network.
RECEIVE PORT (hexadecimal)
•
The port can be defined where IP based (IP, GPRS) messages are coming to the
monitoring station. Configuration is in hexadecimal mode, but in brackets the decimal
port number also can be seen.
PROGRAM PORT (hexadecimal)
•
The port can be defined where receiver remote programming (through Internet) is
possible. Configuration is in hexadecimal mode, but in brackets the decimal port
number also can be seen.
Note: For the operation of remote programming the IP ADDRESS and PROGRAM
PORT should be enabled in rooter as well (Port Forward / Virtual Server / NAT in rooter
menu).
IP MONITORING
•
If this option is enabled, the first 255 (from receiver startup) user accounts received
through IP channel will be monitored. If there is no event with the given user account
through IP line until the MONITOR PERIOD, the receiver will generate IP
Communication Error message with the given client account.
TEST FILTER
•
If IP MONITORING is enabled, this option can be used to filter test code by the receiver.
The defined event codes in CID TEST EVENT menus will be filtered, the first test event
after midnight / receiver start (for each user accounts) is always displayed.
MONITORING PERIOD
•
The time period can be defined within the receiver wait IP communication for the first
255 user accounts. If there is no event with the given user account through IP line until
this period, the receiver will generate IP Communication Error message with the given
client account.
