3Com VCX V7000 Telephone Manual page 39

Figure 5 VCX 3105
1
2
3
4
1 Transfer button — Enables you to send a call to another telephone. See
Transferring a Call.
2 Hold button — Places a caller on hold. See
3 Conference button — Allows you to set up a three-way conference call.
See Setting up a Conference
4 Call Park button — Places a call in a "holding pattern" so that it can be
retrieved from any other telephone on the system. See
Attendant Serial Call button — Enables you to send a call to another
telephone like Transfer, but the call rings back to you when the
destination hangs up. You can perform another transfer or other action.
Not mapped to a button by default, your administrator can map
Attendant Serial Call to any of the four buttons. See
5 Labels — You can print labels for your Attendant Console using the
LabelMaker utility, which is available through the 3Com web site. See
Printing Labels.
6 Label cover tabs — Allow you to unsnap the plastic cover to insert
labels.
Attendant Console
5
8
Call.
VCX Attendant Console
6
7
Putting a Call on Hold.
Call Park.
Serial Transfer.
39
