Remapping Model 2120 Button Functions - 3Com VCX V7000 Telephone Manual

Remapping Model
2120 Button
Functions
Assigning Model 2102 Access Button Functions Using the TUI
Table 4 3Com Default Button Mappings for the Model 2102 Telephone
Button Number
6
5
4
3
2
1
To change the function of a button that is in an unlocked state:
1 Press the Program button twice.
The Display Panel prompts you to select the button you want to remap.
2 Press the button.
The Display Panel prompts you to select the function you want to map to
the button.
3 Select a function.
If you know the Feature Code of the function, enter the number
(see Table 11
If you do not know the Feature Code, scroll through the list of
available functions.
The Display Panel prompts you for any additional information required by
the function.
Feature
Personal Speed Dial #5
Personal Speed Dial #6
Personal Speed Dial #7
System Line #3
System Line #2
System Line #1
in Chapter 6).
Additional Information
Fifth personal speed dial
number
Sixth personal speed dial
number
Seventh personal speed dial
number
Third line for
making/receiving calls; cannot
be reconfigured
Second line for
making/receiving calls; cannot
be reconfigured
First line for making/receiving
calls; cannot be reconfigured
25
