Installing the 3102
Telephone Label
Plate
Attaching and
Adjusting the
Articulating
Support Bracket
I M
NSTALLATION AND AINTENANCE
The VCX 3102 Business Telephone has a label plate with localized button
labels that you must install. Once you snap the plate onto the telephone,
you cannot remove it.
To install the plate, slip the tabs along the top edge of the plate into the
slots on the telephone, and then press firmly along the bottom edge of
the plate until you feel it snap into place.
Figure 8 VCX 3102 Label Plate
The articulating support bracket is common to the following devices:
3Com 3105 Attendant Console
3Com 3102 Business Telephone
Figure 9, Figure 10, and
instructions apply to all telephones.
Figure 11 show a 3102 Telephone. The
