Dialing System Speed
Dial Numbers

Call Forwarding

You can also use the following method to dial a speed dial number on
any VCX phone:
1 Press the Program button.
The Display Panel lists the first speed dial, for example:
Speed dial 1
1001
Use the up and down scroll buttons to locate the speed dial number
you want to dial.
2 Press the first soft button under the Display Panel.
Your phone dials the number.
To exit the speed dial list in the Display Panel, press the third soft button.
In addition to using the Program menu to list speed dial numbers, you
can view the speed dial numbers configured on your phone by pressing
Feature + 463.
The administrator can set up system-wide speed dials for numbers that
are dialed frequently by many internal users. You can view the
system-wide speed dial list through the VCX User Interface (see
Chapter 8 for information) or you can view and dial numbers from it
using the telephone display panel.
To use a system speed dial number:
1 Pick up the handset or press the Speaker button.
2 Press the Feature button plus 700 plus the system-wide speed dial
number for the number that you want to call. Alternatively, you can scroll
to System Speed Dials on the Display Panel, press Slct, scroll to the
number that you want to dial, and press Slct again.
If you dial a speed dial code that has no number assigned to it, the display
panel on your telephone shows the message "No number stored."
This section describes how to enable and use call forwarding features set
up through the Telephone User Interface (TUI). You can also configure
and enable call forwarding through the VCX User Interface. See
Call Forwarding.
You can use the TUI on your phone to specify:
:
Call Forwarding 83
Enabling
