Line Status Lights

Assigning Model
2102 Access Button
Functions Using the
TUI
The next 7 buttons are set to the first seven speed dial codes that you
assign using the VCX User Interface through your web browser or the
telephone keypad. See
8 These three Access buttons (System Appearance buttons; SA1, SA2, and
SA3) are lines for incoming and outgoing calls.
The light for each Access button for each line (system appearance)
indicates the status of the button.
with the status of each line.
Table 3 Status Indicator Lights
Light Status
Off The line is available for use.
Steady The line is in use.
Fast blink The line is ringing.
Slow blink The line is on hold.
When you are on a call, you can answer another call while the line status
light is flashing. Put the first call on hold and then press the Access
button for the new incoming call.
This section describes how to use the Telephone User Interface (TUI) to
view, and possibly modify, the VCX features associated with the Access
buttons on your telephone. You can also use the VCX User Interface to
view and modify button mappings (see
Functions Using the VCX User
When a VCX system is configured, your administrator assigns (maps)
default functions for the Access buttons on your telephone. Mapping a
function to a button allows one-touch access to that function. Speed
dialing is one example of a one-touch function.
Your administrator may allow you to reprogram a button's function (for
example, create more personal speed dial buttons). Consequently, a
programmable button is one of the following states:
Locked — Button function can be changed only by the administrator.
Speed Dialing.
Table 3 lists the light pattern associated
Assigning Access Button
Interface).
