Chapter 2
The FOCUS GC User Interface

Overview

The user interface has three components:
•
•
•
Figure 2-1 illustrates the complete FOCUS GC user interface.

The Display

The display shows the menus you use to control the GC parameters, settings, and
configuration options. The data entry keys allow you to scroll through, set, and
modify the menu information.
Figure 2-2 shows the components of a typical menu display.
42
two line display
display LEDs showing the instrument's status
a keypad for data entry.
Figure 2-1. The FOCUS GC User Interface
