AD7091R User Guide
EVAL-AD7091RSDZ
Follow these steps to quickly evaluate the AD7091R:
1. Install the EVAL-AD7091RSDZ
CD. Ensure that the EVAL-SDP-CB1Z
nected from the USB port of the PC while installing the
software. The PC may need to be restarted after the
installation.
2. Ensure that the default link options are configured as
outlined in Table 2.
3. Connect the EVAL-SDP-CB1Z
AD7091RSDZ board as shown in Figure 2.
4. Screw the two boards together with the enclosed nylon
screw/nut set to ensure that the boards connect firmly
together.
QUICK START GUIDE
software from the enclosed
board is discon-
board to the EVAL-
USB
INTERFACE
SDP BOARD
Figure 2. Hardware Configuration—Setting Up the
5. Connect the power supply adapter included in the kit to
Connecter J1 on the
6. Connect the
USB cable. For Windows® XP, you may need to search for
the EVAL-SDP-CB1Z
search for the drivers for the
prompted by the operating system.
7. Launch the AD7091R software from the Analog Devices
subfolder in the Programs menu.
8. Connect a bipolar input signal via the VINB connector, J6.
9. Remove LK4.
BUFFER
STAGE
AD7091R
POWER SUPPLIES
EVAL-AD7091RSDZ
Rev. 0 | Page 3 of 20
EVAL-AD7091RSDZ
EVAL-SDP-CB1Z board to the PC via the
drivers. Choose to automatically
EVAL-SDP-CB1Z
INPUT
SIGNAL
BIAS UP
9V
DC INPUT
UG-409
board.
board if
