SPECIFICATIONS

GENERAL
• Frequency coverage
[Marine] TX
RX
[LMR] TX/RX
• Mode
[Marine]
[LMR]
• Channel spacing
• Number of programmable ch.
• Power supply requirement
• Current drain (at 7.5 V DC)
• Useable temperature range
[Marine]
[LMR]
• Frequency stability
• Antenna impedance
• Dimensions
(Projections not included)
• Weight (with BP-225)
30
: 156.025–157.425 MHz
156.050–163.275 MHz
146.000–174.000 MHz
: 16K0G3E (Wide)
: 16K0F3E (Wide)/8K50F3E (Narrow)
: 25 kHz (Wide)
12.5 kHz (Narrow; LMR only)
: 100 channels
: BP-223, BP-224 or BP-225 only
: TX High (5 W) 1.6 A typical
TX Mid. (3 W) 1.2 A typical
TX Low (1 W) 0.7 A typical
RX Max audio 200 mA typical
RX Power save 20 mA typical
: –20°C to +60°C; –4°F to +140°F
: –30°C to +60°C; –22°F to +140°F
: ±5 ppm
(–30°C to +60°C;
–22°F to +140°F)
: 50 Ω
: 65(W) × 145(H) × 44(D) mm
(W) × 5 (H) × 1
2 ⁄ ⁄ ⁄ (D) inch
9 23 3
16 32 4
: Approx. 410 g (14.46 oz)
TRANSMITTER
• Output power (at 7.5 V DC)
• Modulation system
• Microphone impedance
• Max. frequency deviation
[Marine]
[LMR]
• Adjacent channel power
[Marine]
[LMR]
• Spurious emissions
RECEIVER
• Receive system
• Sensitivity (12 dB SINAD)
• Squelch sensitivity
• Intermodulation rejection ratio
• Spurious response rejection ratio : 70 dB typical
• Adjacent channel selectivity (Typical)
[Marine]
[LMR]
• Audio output power
All stated specifications are subject to change without notice
or obligation.
: 5 W (Hi), 3 W (Middle) and
1 W (Low)
: Variable reactance frequency
modulation
: 2 kΩ
: ±5 kHz
: ±5 kHz (Wide), ±2.5 kHz (Narrow)
: 70 dB
: 70 dB (Wide), 60 dB (Narrow)
: Less than –70 dBc typical
: Double-conversion
superheterodyne
: 0.25 µV typical
: Less than 0.35 µV typical
(at threshold)
: 70 dB typical
: 70 dB
: 70 dB (Wide), 60 dB (Narrow)
: 0.35 W typical at 10% distor-
tion with an 8 Ω load
