Introduction

This guide is designed to act as a guideline to enable quick installation of the
Tandberg StorageLoader series. For additional product and operation details please
refer to the Tandberg Data DLT VS160 StorageLoader Installation and User manual
P/N 43 30 61 - 01, which can be found on the documentation resource CD included
with the unit.
Installation of the StorageLoader may be quickly summarized in steps as follows:
• Unpack the StorageLoader
• Connect the power cable to the StorageLoader
• Turn the StorageLoader on and follow the instructions given in the LCD display
• Remove the shipment locking screw, and put the magazine back in place
• Select the appropriate SCSI ID's and unit options
• Connect the SCSI interface cable, and optionally the Ethernet cable
• Select IP-address for "Remote Management"
• Install the backup application software (User Supplied) and configure it for use
with the StorageLoader
• Load recording media into the removable magazines
In order to complete full installation of the StorageLoader the following additional
materials are required.
• Simple hand tools- small Phillips screwdriver.
• Tool for emergency magazine removal (included in accessory kit)
• SCSI Host adapter card with 68 pin wide HD or VHDC connector
• Tape Application software which is verified with the StorageLoader
• Up to 8 pieces of the appropriate DLT VS1 recording media to "stock" the
StorageLoader to full tape capacity.
