Installing the Rail Right Assembly

Follow the instruction for left side only using the "Rail Right Assembly
right side of the rack.
Step 5
(Screw
M6x12)
Step 3
(Screw M4x12,
nut and washer)
Picture showing Step 5 above:
Rack Mounting Kit mounted in rack with one
screw M6x12 in upper hole on both left and
right side.
On the rear side two screws must be used on
both left and right side.
Totally six screws are used to install the
Rack Mounting Kit to the rack.
StorageLoader Quick Installation Guide
Rear Rack
Mount Rail
Step 1
Use these holes
if rack depth is
equal or longer
than the
StorageLoader
Step 2
StorageLoader
"
on the
Step 1
Holes to be
used if rack
depth is shorter
than the
StorageLoader
Front Rack Mount Rail
Step 5
(Screw M6x12)
9
