Tandberg Data
Mounting the StorageLoader to the Rack
Make sure that all the screws in the Rack Mounting Kit are tightened properly
before installing the StorageLoader in the rack.
Slide the StorageLoader on the
Rack Mounting Kit from the
front of the rack.
Mount
the
using one M6x12 screw in
front of the rack on both left
and right side
Fix rear end of StorageLoader
to the Rack Mounting Kit by
using one M5x8 screw on both
left and right side.
10
StorageLoader
StorageLoader Quick Installation Guide
