generAl PerformAnCe dATA
Blower models
models With or Without Blower enclosure ➀ ➁
6-580.7
Alternate drives for 575v
➂
drive for drive for
model
under 575v 575v
1/4 - 191 = 1/4 - 197
1/3 - 191 = 1/3 - 197
150
1/3 - 95 = 1/3 - 96
1 - 38 = 1 - 254
1/3 - 95 = 1/3 - 96
175 1 - 192 = 1 - 256
1-1/2 - 193 = 1-1/2 - 198
1/4 - 212 = 1/4 - 213
1/3 - 212 = 1/3 - 213
200
1/3 - 102 = 1/3 - 101
1 - 16 = 1 - 178
1-1/2 - 105 = 1-1/2 - 180
1/3 - 203 = 1/3 - 204
250
1 - 205 = 1 - 157
1-1/2 - 105 = 1-1/2 - 180
1 - 205 = 1 - 157
300 1-1/2 - 106 = 1-1/2 - 108
1-1/2 - 105 = 1-1/2 - 180
1 - 205 = 1 - 157
350 1-1/2 - 105 = 1-1/2 - 180
1-1/2 - 100 = 1-1/2 - 210
400 1-1/2 - 105 = 1-1/2 - 180
Alternate drives for 230/460v
➂
hP & drive hP & drive
model
listed needed
150
1 - 38 = 1 - 254
1 - 192 = 1 - 256
175 1-1/2 - 193 = 1-1/2 - 198
1-1/2 - 79 = 1-1/2 - 80
1 - 16 = 1 - 178
1-1/2 - 105 = 1-1/2 - 180
200
1-1/2 - 23 = 1-1/2 - 177
1 - 205 = 1 - 157
250 1-1/2 - 105 = 1-1/2 - 180
1-1/2 - 23 = 1-1/2 - 177
1 - 205 = 1 - 157
300 1-1/2 - 105 = 1-1/2 - 180
1-1/2 - 23 = 1-1/2 - 177
1 - 205 = 1 - 157
350 1-1/2 - 106 = 1-1/2 - 108
1-1/2 - 105 = 1-1/2 - 180
400 1-1/2 - 105 = 1-1/2 - 180
filters
For blower units with
enclosure and filter, add the
following static pressures
to the static pressure
determined by the system
designer for total external
static pressure.
BdP 150 0.1" W.C.
BdP 175 0.2" W.C.
BdP 200 0.1" W.C.
BdP 250 0.2" W.C.
BdP 300
0.2" W.C.
BdP 350
0.2" W.C.
BdP 400
0.2" W.C.
