5.3.2 Specifications

Demodulation Type
Frequency Range
Frequency Select Method
Frequency Step Size
Channel Spacing
Input Level Desired Carrier
Input Overload
Input Impedance
Input Return Loss
Filtering
Image Rejection
Symbol Rate Range
I/O Connector
5-5–16
QPSK
50 to 90 MHz or 100 to 180 MHz
Synthesized
2.5 KHz
.7 Times the Data Rate
Divided by the Encoding Rate.
-55 to -30 dBm
0 dBm max
75 W (50 Optional)
20 dB minimum
Nyquist, 8 pole, 1 of 4 selectable
40 dB minimum
9.1 to 3152 Kb/s
DIN - 96 pin
