SDM-309B Satellite Modem
SYN_xxx"cr"
ICH_xxx"cr"
QCH_xxx"cr"
BCLK_xxx"cr"
BERT_xxx"cr"
RSL_-nn.ndBm"cr"
CSV_snnnnn"cr"
SFLT_xx"cr""lf"]
5.5 Common Equipment Status
The common equipment status command causes a block of data to be returned which
indicates the status of the common equipment.
Command:
Response:
M&C_xxx"cr
INT_xxx"cr"
BAT_xxx"cr"
PS1_xxx"cr"
PS2_xxx"cr"
PS3_xxx"cr"
MODE_xxxxxx"cr"
SW_x.xxx"cr"
SFLT_xx"cr""lf"]
5.6 Interface Transmit Side Status
Command:
Response:
CLK_xxx"cr"
DRP_xxx"cr"
TXD_xxx"cr"
SFLT_xx"cr""lf"]
5.7 Interface Receive Side Status
Command:
Response:
MUX_xxx"cr"
CLK_xxx"cr"
INS_xxx"cr"
BWA_xxx"cr"
BER_xxx"cr"
RXD_xxx"cr"
OVFL_xxx"cr"
UNFL_xxx"cr"
IRES_xxxx_n.nE-e"cr"
IBFS_nn%"cr"
SFLT_xx"cr""lf"]
MN/U-SDM309B Rev. #
<add/CES_"cr"
>add/CES_"cr"
<add/ITXS_"cr"
>add/ITXS_"cr"
<add/IRXS_"cr"
add/IRXS_"cr"
Synthesizer lock (OK/FLT)
I-channel (OK/FLT)
Q-channel (OK/FLT)
bit clock (OK/FLT)
BER threshold (OK/FLT)
Receive Signal Level (level or No Data)
Current Sweep Value
Number of stored faults logged (0 to 10)
Monitor & Control Module (OK/FLT)
Data Interface Module (OK/FLT)
battery (OK/FLT)
+5 volt power supply (OK/FLT)
+12 volt power supply (OK/FLT)
-12 volt power supply (OK/FLT)
Mode (LOCAL or REMOTE)
Software Version
Number of stored faults logged (0 to 10)
Selected Transmit Clock Activity (OK/FLT)
Drop (OK/FLT)
Transmit Data (OK/FLT)
Number of Stored Faults Logged (0 to 10)
MUX Lock (OK/FLT)
Selected Insert Clock Activity (OK/FLT)
Insert (OK/FLT)
Receive Backward Alarm (OK/FLT)
Frame BER (OK/FLT)
Receive Data Loss/AIS (OK/FLT)
Buffer Overflow (OK/FLT)
Buffer Underflow (OK/FLT)
Read Error Status
Interface Buffer Fill Status
Number of Stored Faults Logged (0 to 10)
Remote Control
B-B–19
