Hot Plugging Console Ports
The keyboard, monitor, and mouse can all be hot plugged.
When hot plugging the mouse:
•
You may unplug and re-plug it as long as you use the same mouse.
•
If you plug in a different mouse, all the computers on the installation must be shut down for 10
seconds, then restarted following the power up sequence
Note: If after hot plugging there is no response to the keyboard and/or mouse input, perform a Keyboard
and Mouse Reset by simultaneously pressing the 1 and 2 front panel port LEDs.
Port Selection
The GCS1716 provides three port selection methods to access the computers on the installation:
1) Manual,
2) An On-Screen Display (OSD) menu system, and
3) Hotkeys.
29
