Front panel

EMG

OFF/VOL

DW / EMG Key

This key is used to enable the DW (Dual Watch) function and the EMG (Emergency Channels) function.

DW (Dual Watch)

The DW (Dual Watch) function allows automatic monitoring of two programmable channels. Refer to the following

procedures to enable this function. Select the first channel to monitor using the channel selector knob (6) or the

channel selector keys on the microphone (18, 20). Press the DW key for about 1.5 seconds and the DW icon will

blink on the LCD display. Select now the second channel to monitor, following the same procedure. Finally press the

DW key for about 1.5 seconds and the two programmed channels will be alternately indicated on the LCD display.

Radio will automatically start monitoring (scanning) the two programmed channels. When a signal is detected on one

of the channels, scanning stops and it is possible to listen to communication on that channel. It is possible to transmit

on the channel, by pressing the PTT key (17). If there is no transmission within 5 seconds, radio will start scanning

the two channels again. When the DW function is enabled, the DW icon (F) appears on the LCD display. To exit the

DW function, shortly press the DW key or the PTT key (17).

EMG (Emergency Channels)

Shortly press the DW/EMG key to select the emergency channels. Two emergency channels (CH9, CH19) are pre-

programmed according to the selected frequency band (refer to the following table). Each time the key is shortly

pressed, radio selects CH19, then CH9, then the normal operating channel. When an emergency channel is selected

(CH9, CH19), the EMG icon (N) appears on the LCD display.

FREQUENCY BAND

ID CODE

CH-9

CH-19
