Product Overview

Back Panel

Back Panel
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster
The access point's Reset button, Ethernet port and Power port are located on the
back panel.
Reset
factory default configuration:
•
•
CAUTION
settings and replaces them with the factory defaults. Before
resetting the access point, save your settings to disk so you can
restore them later, as described in
Configuration" on page
ETHERNET Port
devices, such as a switch or router that may or may not support
PoE.
POWER
power adapter. Use this port if you do not have a PoE switch in your
network.
There are two ways to reset the access point's
Button—
Press the Reset button for approximately ten seconds.
Restore the default settings using the access point's
web-based configuration utility.
Resetting the access point erases all of your custom
68.
—Connects the access point to Ethernet network
Port—Connects the access point to power using the supplied
"Managing the Access Point's
