Getting Started
Navigating the Web-Based Utility
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster

Wireless

This window allows you to enter a variety of wireless settings for the access point.
• Basic Wireless Settings—Chooses the wireless network mode (for
example, wireless-G), wireless channel, and SSID configuration on this
window.
• Wireless Security—Configures the access point's security settings
including access authentication, data encryption, and wireless isolation.
• Wireless Connection Control—Populates your access list to permit or
block specific MAC addresses from accessing your wireless network.
• Advanced Wireless Settings—Configures the access point's more
advanced wireless settings such as beacon interval and output power.
• VLAN & QoS—Configures the VLAN and QoS related settings for the
access point.

AP Mode

This window allows you to configure the access point operation mode with the
Wireless Distribution System (WDS).

Administration

This window allows you to manage the access point:
• Management—Configures the password and Simple Network
Management Protocol (SNMP) settings.
• Log—Configures the log settings for the access point.
• Factory Default—Resets the access point to its factory default settings.
• Firmware Upgrade—Upgrades the access point's firmware on this
window.
• Reboot—Reboots the access point.
• Config Management—Backs up the configuration file for the access point,
as well as uploads the backup configuration file to the access point.
