Installing the Access Point

Placement Tips

Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster
This chapter explains how to mount and connect the Cisco WAP200 Wireless-G
Access Point with Power Over Ethernet and Rangebooster. The following topics
are included:
• Placement Tips, page 9
• Stand Option, page 10
• Wall-Mount Option, page 11
• Connecting the Equipment, page 12
• Verifying the Hardware Installation, page 14
You can place the access point horizontally on its rubber feet, vertically in a stand,
or mount it on the wall.
• Ambient Temperature—To prevent the Product Number Here from
overheating, do not operate it in an area that exceeds an ambient
temperature of 104°F (40°C).
• Air Flow—Be sure that there is adequate air flow around the Product
Number Here.
• Mechanical Loading—Be sure that the Product Number Here is level and
stable to avoid any hazardous conditions.
