- Page 1 User’s Manual P/2 DA2 WM F, WM EC F, P/2 DA2 D, and AAP models Distribution Amplifiers 68-463-02 Rev. C 09 08 © 2008 Extron Electronics. All rights reserved.
- Page 2 Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor.
-
Page 3: Fcc Class A Notice
FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Table Of Contents
Front and Rear Panels ... Front faceplate ... 2-2 P/2 DA2 WM F/EC F rear panel ... 2-4 P/2 DA2 D rear panel ... 2-5 Installing the P/2 DA2 WM F/EC F ... Easy setup procedure ... 2-7 Installing the mud ring bracket ... 2-8 Cabling ... -
Page 5: Chapter 1 • Introduction
... A-15 P/2 DA2 WM F mounting template ... A-15 P/2 DA2 WM F AAP mounting template ... A-16 P/2 DA2 D mounting template ... A-17 All trademarks mentioned in this manual are the properties of their respective owners. P/2 DA2 WM/EC/D/AAP Series • • • • • Table of Contents 68-463-02 Rev. -
Page 6: About The P/2 Da2 Wm F/Ec F, Aap And D Models
P/2 DA2 WM/EC/D/AAP Series • Introduction ® faceplates and trim. P/2 DA2 WM/EC/D/AAP Series Chapter Two Controls and Installation Front and Rear Panels Installing the P/2 DA2 WM F/EC F Installing the P/2 DA2 D P/2 DA2 WM/EC/D/AAP Series • Introduction... -
Page 7: Front And Rear Panels
50% – increases the output signal level and adds 50% of the maximum peaking to the signal P/2 DA2 WM EC F faceplate features P/2 DA2 D faceplate features P/2 DA2 WM/EC/D/AAP Series • Controls and Installation If the edges of the image seem to exceed their boundaries, or if thin lines and sharp edges look thick and fuzzy, try changing the level/peak setting. -
Page 8: P/2 Da2 Wm F/Ec F Rear Panel
Figure 2-5 — P/2 DA2 D rear connectors Configuration DIP switches — The three DIP switches (plus one spare) configure the P/2 DA2 D, as shown in the table below. The default DIP switch positions are set to On (up). -
Page 9: Installing The P/2 Da2 Wm F/Ec F
& gain P/2 DA2 D (viewed from rear) Adjust the gain before installing the P/2 DA2 D into a wall, as the gain switch will be inaccessible after installation. Power input — Connect the included 12 VDC external power supply into the 2-pole, 3.5 mm captive screw connector. Be careful to observe the correct polarity. -
Page 10: Installing The Mud Ring Bracket
Controls and Installation, cont’d Power up all of the input and output devices. The image should now display on screen. If it does not, double check steps 3 through 6 and make adjustments as needed. Refer to the section “Setting the DIP switches” in this chapter. -
Page 11: Cabling
Controls and Installation, cont’d Cabling The P/2 DA2 WM F cabling diagram below shows how to connect input and output devices to the distribution amplifier’s front panel. The P/2 DA2 WM EC F model has identical connectors. AUTO POWER 100% UNITY GAIN/PEAKING P/2 DA2 WM F cabling... -
Page 12: Installing Architectural Adapter Plates
Controls and Installation, cont’d Balanced audio To attach the distribution amplifier to a balanced audio system, do the following: Attach the audio cable to a balanced speaker input connector (tip, ring, and sleeve). Tip (L) Ring (R) Sleeve ( ) Attach the audio cable to the audio cable connector (Extron part number 10-319-10). -
Page 13: P/2 Da2 Wm F Wall Mount Installation
Controls and Installation, cont’d P/2 DA2 WM F wall mount installation Once the input and output cables have been connected and the P/2 DA2 WM F has been successfully tested, the faceplate may be attached to the mounting bracket using the four supplied screws. -
Page 14: Setting The Internal Jumpers
1-2 = Local Monitor (default) 2-3 = Data Display Installing the P/2 DA2 D The P/2 DA2 D is a wall-mounted product and can be mounted into an electrical wall box. These instructions include site preparation, wall box installation, and the mounting of the distribution amplifier in the wall box. -
Page 15: Mounting The Distribution Amplifier
Controls and Installation, cont’d Wall Stud Installation Cable Installation Cable Cable Clamp Cable Clamp Screws or Nails Screws or Nails Attaching the wall box to a wall stud If attaching the wall box to wood, use four #8 or #10 screws or 10-penny nails. -
Page 16: Replacing The Faceplate
NORM HIGH Back Panel Faceplate (rear) P/2 DA2 D application example An example of the P/2 DA2 D installation is shown below. Projector IN P Extron MHR-5 Cable Audio Extron... -
Page 17: Specifications
Minimum/maximum levels ... Analog: 0.4 V to 1.4 Vp-p (follows input) Impedance ... 75 ohms Return loss (P/2 DA2 D) ... <-38 dB @ 5 MHzP/2 DA2 WM F, P/2 DA2 WM F AAP<-40 dB @ 5 MHz DC offset (P/2 DA2 D) ... ±5 mV with input at 0 offset Sync Input type ... -
Page 18: Audio Input
Crosstalk (P/2 DA2 D) ... <-80 dB @ 1 kHz Stereo channel separation (P/2 DA2 D) >80 dB @ 1 kHz CMRR (P/2 DA2 D) ... >67 dB @ 20 Hz to 20 kHz Audio input Number/signal type ... 1 stereo, unbalanced Connectors ... -
Page 19: Dimensions
(6.6 cm H x 9.4 cm W x 4.1 cm D) Product weight P/2 DA2 D ... 0.2 lbs (0.1 kg) P/2 DA2 WM F ... 0.4 lbs (0.2 kg) P/2 DA2 WM F AAP ... 0.6 lbs (0.3 kg) Shipping weight ... -
Page 20: P/2 Da2 Wm F Aap Faceplate Dimensions
Specifications, Dimensions, and Parts, cont’d P/2 DA2 WM F AAP faceplate dimensions WM F AAP model faceplate dimensions P/2 DA2 WM/EC/D/AAP Series • Appendix P/2 DA2 D faceplate dimensions .060 [1.524] .600 [15.500] .100 [2.540] 2.830 [71.882] 2.720 [69.088] 0.110 [2.794] 0.000 [0.000]... -
Page 21: Part And Accessories
P/2 DA2 EC F (RAL9010 white) P/2 DA2 WM F AAP (black, white, RAL9010 white) P/2 DA2 WM EC F AAP (RAL9010 white) 60-377-10 P/2 DA2 D (black, white) User manual Cables The table below lists various lengths of high resolution VGA cables which can be used with the P/2 DA2 WM F/WM F AAP/ EC F/D models. - Page 22 Specifications, Dimensions, and Parts, cont’d A-12 P/2 DA2 WM/EC/D/AAP Series • Appendix P/2 DA2 WM/EC/D/AAP Series • Appendix A-13...
-
Page 23: P/2 Da2 Wm F Mounting Template
Specifications, Dimensions, and Parts, cont’d A-14 P/2 DA2 WM/EC/D/AAP Series • Appendix Templates Use these templates as a guide for cutting the hole in the installation surface (wall or furniture). This templates for the P/2 DA2 WM F and the P/2 DA 2 WM F AAP are not full size. -
Page 24: P/2 Da2 Wm F Aap Mounting Template
FURNITURE MOUNT 7.31" (18.28 cm) TEMPLATE IS NOT FULL SIZE. A-16 P/2 DA2 WM/EC/D/AAP Series • Appendix P/2 DA2 D mounting template Cut-Out Template for Extron's Wall Plate To install P/2 DA2 directly into furniture or wall, cut along this line. - Page 25 Specifications, Dimensions, and Parts, cont’d A-18 P/2 DA2 WM/EC/D/AAP Series • Appendix...
