Appendix B - Technical Specifications
Audio Codec
• GSM-AMR: 12.2Kbps
• PCM: 8Kbps
Light Sensitivity
• 1 lux@F2.8
Digital Zoom
• Up to 16X
3A Control
• AGC (Auto Gain Control)
• AWB ( Auto White Balance)
• AES (Auto Electronic Shutter)
Power
• Input: 100-240VAC, 50/60Hz
• Output: 5VDC, 2.5A
• Powered by an external power adapter
• Maximum power consumption
DCS-1130: 6.3W
Dimensions (WxDxH)
• 120.0mm x 81.5mm x 38.0mm
(without bracket and stand)
Weight
• DCS-1130: 280g (without bracket and stand)
Operation Temperature
• 0˚ to 40˚C (32˚ to 104˚F)
Storage Temperature
•- 20˚ to 70˚C (-4˚ to 158˚F)
D-Link DCS-1130 User Manual
Humidity
• 20-80% RH non-condensing
Emission (EMI), Safety & Other Certifications
• FCC Class B
• IC
• C-Tick
• CE
46
