Datasheet; Tx Fifo Registers ($ 0X600 - 0X63E) - Intel IXF1104 Datasheet

Table 64. RX FIFO Registers ($ 0x580 - 0x5BF) (Sheet 2 of 2)
Register
"RX FIFO Low Watermark Port 3 ($0x58D)"
Reserved
RX FIFO Overflow Frame Drop Counter Port 0
RX FIFO Overflow Frame Drop Counter Port 1
RX FIFO Overflow Frame Drop Counter Port 2
RX FIFO Overflow Frame Drop Counter Port 3
Reserved
"RX FIFO Port Reset ($0x59E)"
"RX FIFO Errored Frame Drop Enable ($0x59F)"
"RX FIFO Overflow Event ($0x5A0)"
Reserved
RX FIFO Errored Frame Drop Counter Port 0
RX FIFO Errored Frame Drop Counter Port 1
RX FIFO Errored Frame Drop Counter Port 2
RX FIFO Errored Frame Drop Counter Port 3
Reserved
"RX FIFO SPI3 Loopback Enable for Ports 0 - 3
($0x5B2)"
"RX FIFO Padding and CRC Strip Enable ($0x5B3)"
Reserved
"RX FIFO Transfer Threshold Port 0 ($0x5B8)"
"RX FIFO Transfer Threshold Port 1 ($0x5B9)"
"RX FIFO Transfer Threshold Port 2 ($0x5BA)"
"RX FIFO Transfer Threshold Port 3 ($0x5BB)"
Reserved
Table 65. TX FIFO Registers ($ 0x600 - 0x63E) (Sheet 1 of 2)
Register
TX FIFO High Watermark Port 0
TX FIFO High Watermark Port 1
TX FIFO High Watermark Port 2
TX FIFO High Watermark Port 3
Reserved
TX FIFO Low Watermark Port 0
TX FIFO Low Watermark Port 1
TX FIFO Low Watermark Port 2
TX FIFO Low Watermark Port 3

Datasheet

Document Number: 278757
Revision Number: 009
Revision Date: 27-Oct-2005
®
Intel IXF1104 4-Port Gigabit Ethernet Media Access Controller
1
Bit Size Mode Ref Page
32 R/W 195
32 RO –
32 R 195
32 R 195
32 R 195
32 R 195
32 RO –
32 R/W 196
32 R/W 196
32 R 197
32 R –
32 R 198
32 R 198
32 R 198
32 R 198
32 RO –
32 R/W 199
32 R/W 200
32 R –
32 R/W 201
32 R/W 201
32 R/W 201
32 R/W 202
32 R –
1
Bit Size Mode Ref Page
32 R/W 203
32 R/W 203
32 R/W 203
32 R/W 203
32 RO –
32 R/W 204
32 R/W 204
32 R/W 204
32 R/W 204
Address
0x58D
0x58E - 0x593
0x594
0x595
0x596
0x597
0x598 - 0x59D
0x59E
0x59F
0x5A0
0x5A1 - 0x5A5
0x5A2
0x5A3
0x5A4
0x5A5
0x5A6 - 0x5B1
0x5B2
0x5B3
0x5B4 - 0x5B7
0x5B8
0x5B9
0x5BA
0x5BB
0x5BC - 0x5BF
Address
0x600
0x601
0x602
0x603
0x604 - 0x609
0x60A
0x60B
0x60C
0x60D
160
