Pr. 340
Operation Mode
Setting
Pr. 79
0 PU or external operation
1 PU operation
2 External operation
External/PU combined
3
operation
External/PU combined
4
operation
5* Programmed operation
1, 2
6 Switch-over
7 PU operation interlock
Operation mode switch-
8
over by the external signal
* Programmed operation is available only with the FR-A500(L) series.
Mode at Power On or at Restoration
from Instantaneous Power Failure
Inverter operates in the computer link operation mode.
(Program need not be used for switching)
Inverter operates in the PU operation mode.
Inverter operates in the computer link operation mode.
(Program need not be used for switching.)
Operation command is set in the PU operation mode and the start com-
mand is set in the external operation mode.
Operation command is set in the external operation mode and the start
command is set in the PU operation mode.
Inverter operates in the programmed operation mode.
Inverter operates in the computer link operation mode.
Operation mode is switched while running.
Refer to the inverter manual for details.
X12 signal ON............ Inverter operates in the computer link operation
mode.
(Operation mode can be switched to the external
operation mode by the program.)
X12 signal OFF .......... Inverter operates in the external operation mode.
X16 signal ON............ Inverter operates in the computer link operation
mode.
(Operation mode can be switched to the external
operation mode by the program.)
X16 signal OFF.......... Inverter operates in the PU operation mode.
