COMPUTER LINK FUNCTION

4.13 Error Code List

The corresponding error code in the following list is displayed if an error is detected in any communication
request data from the computer:
Error Code Item
H0 Computer NAK error
H1 Parity error
H2 Sum check error
H3 Protocol error
H4 Framing error
H5 Overrun error

H6
H7 Character error

H8

H9
HA Mode error
HB Instruction code error The specified command does not exist.
HC Data range error

HD

HE

HF
Definition
The number of errors consecutively detected in
communication request data from the computer is greater
than the permissible number of retries.
The parity check result does not match the specified parity.
Sum check code in the computer does not match that of
the data received by the inverter.
Data received by the inverter is in the wrong syntax, data
receive is not completed within the given time, or CR and
LF are not as set in the parameter.
The stop bit length is not as specified by initialization.
New data has been sent by the computer before the
inverter completes receiving the preceding data.

The character received is invalid (other than 0 to 9, A to F,
control code).


Parameter write was attempted in other than the computer
link operation mode or during inverter operation.
Invalid data has been specified for parameter write,
frequency setting, etc.



41
Inverter Operation
Brought to an alarm
stop (E.OP1 to E.OP3)
if error occurs
continuously more
than the permissible
number of retries.

Does not accept
receive data but is not
brought to alarm stop.


Does not accept
receive data but is not
brought to alarm stop.



