<Calculation example 1>
Format A'
Inverter
Instruction
ENQ station
code
number
1 2 3 4 5
<Calculation example 2>
Format G
Inverter
ACK station CR LF
number
1 2 3 4 5
Sum
Data CR
check
6 7 8 9 10 11
Number of characters
<Calculation example 2>
1)Baudrate = 9600 bps, number of data char-
acters = 5, stop bit length = 2 bits, data
length = 8 bits, parity check = yes, CR, LF
LF
instructions = yes
Number of
12
1
characters
×5×12 = 0.00625s (6.25ms)
9600
2)Same conditions as above with the excep-
tion of baudrate = 19200 bps
1
×5×12 = 0.003125s (3.125ms)
19200
3)Same conditions as above with the excep-
tion of baudrate = 300 bps
1
×5×12 = 0.2s (200ms)
300
