Instruction
No. Item
Inverter status
4
monitor
Code
H00 to HFF: Inverter status monitor
b7
0 0 0 0 0 0 1 0
(For example 1)
H7A
[Example 1] H02 ...... Forward running
[Example 2] H00 ...... Stop due to alarm
*: Outputs change with the settings of Pr. 190 to Pr. 195 (output terminal
function selection). For details, refer to the Inverter Instruction Manual.
Description
b0: Inverter running (RUN)*
b0
b1: Forward running (STF)
b2: Reverse running (STR)
b3: Up to frequency (SU)*
b4: Overload (OL)*
b5: Instantaneous power failure (IPF)*
b6: Frequency detection (FU)*
occurrence
b7: Alarm occurrence*
38
COMPUTER LINK FUNCTION
